Avantes Product Catalog
Avantes Product Catalog
Avantes is a prominent manufacturer of fiber-optic spectroscopy instruments, serving industries such as biomedical, agriculture, semiconductor, and consumer electronics. Their products cover ultra-violet, visible, and near-infrared wavelengths (200-2500 nm), ensuring high accuracy for diverse applications.
Avantes aims to enhance human life and positively impact the planet through innovative measuring equipment. With nearly 30 years of experience, they have a global presence with headquarters in the Netherlands and offices in the US and China, supported by distributors in over 35 countries.
The catalog includes a wide range of spectrometers, light sources, fiber optics, software, and accessories. Key product lines include the AvaSpec series, featuring advanced CCD and CMOS detectors for precise scanning. Accessories such as cuvette holders and fiber-optic multiplexers enhance the versatility of their spectrometers.
Avantes offers a modular approach, allowing users to customize their spectroscopic setups to meet specific research needs, ensuring flexibility and remarkable results.
Avantes provides software solutions like AvaSoftX and interface packages for Windows and Linux, supporting seamless integration and operation of their spectroscopic systems.
Avantes revolutionized spectrometry by integrating microelectronics, specifically CCD and CMOS detectors, eliminating the need for moving parts. This innovation allows for fast, accurate, and cost-effective scanning. The use of fiber optics technology enhances the versatility and adaptability of Avantes spectrometers, making them suitable for harsh environments.
Avantes spectrometers are used across industries for applications ranging from chemical composition analysis to color measurement and radiometry. They cover a wide range of wavelengths, from ultraviolet to near-infrared.
The optical bench design features a toroid mirror and various components that can be configured to meet specific application needs. Key components include diffraction gratings, entrance slits, and order-sorting filters, which influence sensitivity, resolution, and bandwidth.
- CompactLine: Offers high performance in a small form factor, suitable for OEM and handheld devices.
- StarLine: High-performance spectrometers for general applications, covering wavelengths from 200 to 1100 nm.
Avantes provides a three-year limited warranty on all spectrometers, light sources, and accessories.
The AvaSpec SensLine series is designed for demanding spectroscopy applications such as fluorescence, luminescence, and Raman spectroscopy. These spectrometers feature back-thinned detector technology and advanced thermoelectric cooling, providing high sensitivity and low noise.
The AvaSpec NIRLine is optimized for long-wavelength measurements, featuring InGaAs detectors and thermoelectric cooling. It is ideal for applications like moisture content measurement, plastic characterization, and solar monitoring.
The NEXOSTM Spectrometer is compact and lightweight, available with 2K or 4K CMOS detectors. It offers high-speed performance with integration times as low as 9 μs and minimal stray light.
The VARIUSTM spectrometer is designed for versatility, featuring a 2k or 4k pixel detector and compatibility with Avantes accessories and software.
All spectrometers feature a symmetrical Czerny-Turner optical bench design with a 75 mm focal length. They cover a wavelength range of 190 - 1100 nm, with stray light levels between 0.1 - 1%.
The document provides detailed technical specifications and features of various spectrometers offered by Avantes, including the VARIUSTM OEM, AvaSpec-ULS2048XL+, AvaSpec-HERO, AvaSpec-ULS2048x64TEC-EVO, AvaSpec-HS2048XL-EVO, and AvaSpec-NIR256/512-1.7-EVO.
- High-speed data transfer via USB 3.0 and Gigabit Ethernet.
- Robust design for integration into various systems.
- Wide wavelength range coverage from UV to NIR.
- Options for cooling and noise reduction for enhanced performance.
These spectrometers are suitable for a wide range of applications including biomedical fluorescence detection, environmental pollutant analysis, quality control in agriculture and food production, and industrial process monitoring.
The document provides detailed specifications for various Avantes spectrometers, including the AvaSpec-NIR256/512-1.7-EVO, AvaSpec-NIR256/512-1.7-HSC-EVO, AvaSpec-NIR256/512-2.5-HSC-EVO, and AvaSpec Multi-Channel Spectrometer.
The spectrometers feature InGaAs linear array detectors with varying pixel configurations (256 or 512 pixels) and are equipped with a 16-bit AD converter.
The spectrometers utilize a symmetrical Czerny-Turner optical bench with a 100 mm focal length.
Avantes offers Raman spectroscopy solutions with the AvaRaman bundles, which include a spectrometer, laser probe, and software for data analysis.
The document also mentions OEM spectrometer options, such as the AS-7010 microprocessor board and AvaBench optical benches, which are available for integration into custom systems.
The AvaBench series includes models like AvaBench-75-ULS, AvaBench-37.5-HS, and AvaBench-100-HSC, each with specific focal lengths, numerical apertures, and wavelength ranges.
The AvaBench NIR series, including AvaBench-50 and AvaBench-100TEC, is designed for the 1000-2500 nm range.
Avantes provides a DEVKIT for easy IO access, featuring screw terminals, BNC connectors, and RS232 connectors.
Various enclosures are available for different AvaBench and circuit board combinations.
A range of cables is offered for connecting AvaSpec spectrometers to light sources and accessories.
Avantes offers wavelength, non-linearity, and irradiance calibrations, with NIST traceable standards and detailed reports.
AvaSoft and AvaSoftX are Avantes' software solutions for spectrometer control and data analysis, supporting Windows and Linux.
AvaSpec-DLL packages allow for custom software development in Windows and Linux.
The document describes interface packages for Windows and Linux, including the FOM-DLL for fiber-optic multiplexers and the Irradiance-DLL for calculating various parameters from irradiance values.
AvaSoftX is the latest generation of Avantes spectroscopy software, designed to streamline the spectroscopy workflow.
This modular spectroscopy software offers advanced analytical functions and data manipulation capabilities.
Specline provides an extensive database for identifying atoms, ions, and molecules.
Avantes offers a range of light sources, including halogen, xenon, LED, and deuterium, each tailored for specific applications.
Detailed technical data for various light sources are provided, including wavelength range, stability, drift, optical power, and bulb lifetime.
The thermal resistance of fiber-optic assemblies is influenced by the materials used.
Fiber optic probes are available with different temperature ranges and materials.
Avantes offers various fiber-optic cables in different lengths and configurations.
These cables are used for simultaneous multi-point measurements and can function as combiners or splitters.
Reflection probes are used for spectral information of materials.
Designed for thick liquids or powders, these probes feature a stainless steel cylinder and an exchangeable, waterproof tip.
Designed for effective fluorescence measurement with 12 excitation fibers and a 600 μm read fiber.
Used for absorption measurements in small vessels, with a miniaturized tip of 130 mm length and 3.2 mm diameter.
Designed for online and inline absorbance measurements with a standard SMA-905 connector.
Avantes offers custom designs for high-temperature, high-pressure, and vacuum conditions.
Used to convert divergent light beams into parallel beams, optimized for UV/VIS/NIR range.
Collect light from a 180° angle to eliminate optical interface problems.
Designed for use in vacuum chambers with fiber optics, suitable for vacuum levels up to 10-7 millibar.
Allows easy mounting of Avantes spectrometers to microscopes using C-mount adapters.
RPH-1 and AFH-15 holders facilitate positioning of reflection probes for various measurement angles.
Designed to simplify reflection and transmission measurements with multiple setup options.
The document provides detailed specifications and applications for various integrating spheres offered by Avantes.
- AvaSphere-30: Internal diameter 30 mm, sample port diameter 6 mm.
- AvaSphere-50: Internal diameter 50 mm, sample port diameter 10 mm.
- AvaSphere-80: Internal diameter 80 mm, sample port diameter 15 mm.
- AvaSphere-50-LS-HAL: Integrating sphere with an internal halogen light source.
- AvaTrigger External Trigger Box: Enables optical and manual triggering for AvaSpec spectrometers.
- Fiber Optic Switch (FOS-2-INL): Corrects light source drift and supports heavy usage with 5 million cycles.
- Direct-Attach Shutter: Facilitates automatic shuttering for spectrometers.
- In-Line Flow Cells: Available for various tubing diameters.
- Reference Tiles: WS-2 for diffuse reflection and RS-2 for specular reflection.
The integrating spheres and accessories are suitable for a wide range of applications, including color measurements, fluorescence spectroscopy, and gemology.
- Power Input: 100-240 VAC ± 10%/ 47-63 Hz
- Power Consumption: 400 mA for PS-12V/1.0A, 700 mA for PS-24V/1.25A
- Power Output: 12 VDC ± 5% or 24 VDC ± 5%, depending on load
- Output Current (Max): 1.0 A for PS-12V/1.0A, 1.25 A for PS-24V/1.25A, 2.08 A for PS-12V/2.08A
- DC Connector Dimensions: Varying sizes depending on model
- Dimensions: Varying sizes depending on model
- Operating Temperature: 0 - 45°C
- Cable Length: 2.0 m for PS-12V/1.0A, 1.25 m for PS-24V/1.25A
Spectroscopy is used in various industries such as agriculture, food, lighting, biomedical, semiconductor, chemistry, solar, environmental, and OEM.
- Reflection: Measures light intensity reflected from surfaces.
- DOAS: Detects trace gases by observing light absorption changes.
- Transmission: Measures light intensity passing through samples.
- Irradiance: Measures radiant flux on surfaces.
- Absorbance: Quantifies light absorbed by samples.
- Fluorescence: Investigates light emission after excitation.
- LIBS: Analyzes elemental composition using laser-induced plasma.
- Raman: Analyzes molecular vibrations through inelastic light scattering.
For more information, contact Avantes headquarters or regional offices in the USA and China. Visit their website or sign up for their newsletter for updates.
Catalog excerpts
EMPOWERING SPECTROSCOPY SOLUTIONS
Open the catalog to page 1
ABOUT AVANTES Get ready to dive into Avantes’ solutions, where precision meets innovation and endless possibilities await. We are thrilled to present the Avantes Product Catalog, a bundle of cuttingedge spectroscopic solutions designed to elevate your experiments and research. We are Avantes, a leading manufacturer of fiber-optic spectroscopy instruments and systems where cutting-edge technology meets precision and reliability. Our wide range of products caters to various industries, including (bio)medical, agriculture, semiconductor, and consumer electronics, empowering researchers and professionals...
Open the catalog to page 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Spectromer Lines Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 AvaSpec-NEXOS 2K.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 AvaSpec-NEXOS 4K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . ....
Open the catalog to page 3
OUR TECHNOLOGY Traditionally, spectrometers relied on moving gratings to scan the spectrum. However, Avantes revolutionized the field during the 1990s by adopting microelectronics, specifically Charged Coupled Devices (CCD) arrays and complementary metal-oxide-semiconductor (CMOS) detectors. This groundbreaking integration paved the way for our AvaSpec line of spectrometers, known for their fast and accurate scanning capabilities without the need for moving parts. Now, our customers can benefit from efficient and low-cost scanning thanks to these advanced CCD and CMOS detectors integrated into...
Open the catalog to page 4
CompactLine - AvaSpec-NEXOSTM Spectrometer with 2k CMOS Detector SPECTROMETERS At Avantes, we understand that spectroscopy is a diverse and dynamic field with many applications requiring tailored solutions . That's why we've categorized our spectrometers into distinct lines, each specifically engineered to excel in different areas of spectroscopic exploration. Join us as we take you through our four spectrometer lines CompactLine: Size Meets Performance When space is a precious commodity, the CompactLine delivers impressive performance in a small form factor. Our CompactLine boasts one of the...
Open the catalog to page 5
Avantes' NEXOS™ Spectrometer is a small, lightweight, and powerful spectrometer optimized for spectroscopy integration to deliver high-end performance. The device is available with 4K detector, offering high-speed performance, with integration times of up to 9 ps, minimal stray light as low as 0.1%, and a strong signal-to-noise ratio of 365:1. The new powerful and versatile spectrometer is available with USB2 communication . This device can be customized to your needs using six different slit sizes and more than 15 types of gratings. The replaceable slit option is standard for Non-OEM. The NEXOS™...
Open the catalog to page 6
StarLine - AvaSpec-VARIUSTM Spectrometer with 2k CMOS Detector SPECTROMETERS Building on the proven modularity and form factor of the standard NEXOS™, this model features an advanced detector optimized for sensitivity in the 700-1100 nm range. Available with a 2048 or 4096-pixel detector. Experience precision, reliability, and sensitivity all in one device Engineered for researchers and system integrators seeking fast, accurate, and reliable NIR measurements, the NEXOS™ NIR Enhanced is ideal for demanding applications such as food sorting, Raman spectroscopy, and VCSEL/laser system integration...
Open the catalog to page 7
StarLine - AvaSpec-VARIUSTM NIR Enhanced Spectrometer with more precision in the Near-Infrared SPECTROMETERS Meet the VARIUS™, a flexible spectrometer specifically designed to meet the needs of a wide variety of applications. The VARIUS™ is available with a 4k pixel detector, and compatible with Avantes light sources, accessories, and AvaSoft software Crafted with patent-pending technology, the Varius™ redefines versatility, delivering precision like never before Adapt seamlessly to every challenge by replacing the slit with the new cover. Achieve 0.1-1% stray light, superior signal-to-noise...
Open the catalog to page 8
StarLine - AvaSpec-VARIUS™ OEM Spectrometer for Original Equipment Manufacturing customers Meet the VARIUS™OEM, a flexible spectrometer specifically designed for integrating into your product or system. The VARIUS™ OEM is available with a 2k or 4k pixel detector, both of which are compatible with Avantes light sources, accessories, and AvaSoft software. Its robust industrial stainless steel electromagnetic compatible housing contains brackets on the side for easy integration. The VARIUS™ OEM meets the latest EMC requirements for medical devices. Experience highspeed data transfer, stray light...
Open the catalog to page 9
SensLine - AvaSpec-HERO SensLine High resolution & sensitivity spectrometer SensLine - AvaSpec-ULS2048x64TEC-EVO Thermoelectrically Cooled Fiber-Optic Spectrometer The AvaSpec-HERO spectrometer is designed with a High Sensitivity Compact (HSC) optical bench (f=100mm; NA=0.13) and a 1024x58 back-thinned CCD detector, providing high sensitivity and resolution . This instrument is equipped with thermoelectric cooling, allowing long integration times in low-light conditions. The AS7010 electronics, including a high-end AD converter, minimizing noise, resulting in excellent Signal to Noise and Dynamic...
Open the catalog to page 10
High UV and NIR Sensitivity Back-Thinned CCD Spectrometer High UV and NIR Sensitivity Spectrometer The AvaSpec-HS2048XL-EVO is an exceptional instrument for high sensitivity applications where high resolution is not of paramount concern. It features Avantes' HS optical bench, which has a full 0.22 numerical aperture for superior throughput. The back-thinned CCD detector has 2048 large monolithic pixels measuring 14x500 microns, with high efficiency in the UV (200-400 nm) and NIR (950-1160 nm) while retaining sensitivity in the visible range. The unique optical design includes toroid collimating...
