LED Solutions

Product catalog summary

Overview
Avago Technologies is a prominent manufacturer of visible light-emitting diodes (LEDs), offering a wide array of LED solutions. These include high brightness and high power LEDs, PLCC surface-mount LEDs, standard through-hole lamps, flash LEDs, flexible light strip modules, and various LED displays. The products serve diverse markets such as electronic signs, automotive, solid-state lighting, and consumer electronics.

High Brightness Through-hole Lamps
Avago's high brightness through-hole LEDs utilize AlInGaP and InGaN technologies, available in 3 mm, 4 mm, and 5 mm packages. Known for their quality, reliability, and low power consumption, they are ideal for backlighting and status indication in electronic signs, consumer electronics, and automotive interiors.

Features and Benefits

High product quality and reliability
Wide range of products with competitive pricing
Low power consumption and high efficiency
High reliability with no need for replacement during equipment life
Available in multiple colors with high luminous intensity
Various packaging options with different sizes and lens types

Typical Applications

Electronic signs and signals (e.g., road safety signs, exit signs)
Consumer electronics (e.g., gaming and vending machines)
Automotive interiors and other equipment

Surface Mount PLCC LEDs
Designed for high reliability, PLCC surface-mount LEDs are suitable for applications like traffic lights and displays. They feature a wide viewing angle and are compatible with IR-solder reflow and through-the-wave soldering.

Features and Benefits

Industry-standard PLCC SMT package
High brightness using AlInGaP and InGaN technologies
Available in a broad range of colors

Specifications

Intensity Bin Limits: Defined for various bins with specific minimum and maximum values in millicandela (mcd), with a tolerance of ±12%.
Color Bin Limits: Chromaticity coordinates are provided for different color bins, with a tolerance of ±0.02.
VF Bin Limits: Voltage forward (VF) binning for AlInGaP and InGaN devices, with specific voltage ranges and a tolerance of ±0.1V.
Flux Bin Limits: Defined for various bins with specific minimum and maximum values in lumens (lm), with a tolerance of ±12%.

Packaging Options

Various packaging options are available, including top mount and reverse mount configurations, with different reel sizes and current ratings.
Individual reels contain parts from one full or half bin only, ensuring uniformity in intensity and color.

Applications

Interior and exterior automotive lighting, including instrument panel backlighting, turn signals, and rear combination lamps.
Electronic signs and signals, such as channel lettering and indoor variable message signs.
Office automation, home appliances, and industrial equipment, including front panel and display backlighting.

Features and Benefits

High reliability and optical efficiency with a wide 120-degree viewing angle.
Compatible with both IR and TTW soldering processes.
Available in red, red-orange, and amber colors, with high ambient temperature tolerance.

Conclusion
Avago Technologies' LED products offer a comprehensive range of options for various applications, emphasizing high quality, reliability, and efficiency. The detailed specifications and variety of configurations make them suitable for a wide range of consumer, industrial, and automotive applications.
