Ci4000 Weather-Ometer Brochure
1 / 16Pages

Setting the Standard for Xenon Weathering

Focused On Your Goals The Atlas Vision Shaping the future of the materials testing world in partnership with our customers. Atlas pioneers innovative ways for companies to test the weatherability of their products. From our industry-leading accelerated weathering equipment to the consulting services of our expert laboratory staff, our approach to the market is clear: Provide our customers with superior, easy-to-use technology and advanced testing solutions to determine how long their products will last. Every step of the way, Atlas is there - Accelerating Your Expertise. Quality at Every...

Which Light is Right? Choosing the “right light” is one of the first steps in creating an accurate and reliable weathering test program. The Ci4000 simulates solar radiation using xenon lamps and advanced filter systems specifically designed for weathering. Atlas xenon lamps are developed exclusively for weathering to meet high performance criteria for their spectral power distribution, lifetime irradiance stability and lot-to-lot uniformity. The Ci4000 uses interchangeable glass filters that tailor the xenon light spectrum to match light conditions in your products’ end use environment....

FEATURES A Higher Order of Weathering Testing Performance Through Superior Science The Ci4000 Weather-Ometer® with its advanced digital control , system, represents monumental achievement in applying digital and optical technologies in an easy-to-use laboratory weathering instrument. The Ci4000 is approved by many OEMs in the automotive, paints & coatings and plastics industries as the exclusive platform to deliver accurate, reproducible and repeatable results for predicting service life. The Ci4000 has been certified CE, UL, CSA, ISO and EN compliant. Rotating Sample Rack Maximizes...

fluh l.'mjirijiiirr Hxk^mpcfJiurE udcnr Intuitive User Touch Screen Interface Increases functionality that makes the Ci4000 easy to program, monitor and calibrate Programmable Stepped Changes in Irradiance, Temperature, Humidity and Other Test Conditions To meet any user defined test program or cycle Advanced Digital Control Digital control with rugged, state-of-the-art embedded electronics Reduces test variability in chamber temperature and humidity and compensates for changes in ambient laboratory conditions. VibraSonic Humidity Control Accurately replicates humidity levels to meet...

On-screen Trend Plot Monitor All Critical Status Information Monitor and/or plot all critical set points and compare with real time Black Panel Temperature (BPT), Black Standard Temperature (BST) Water Quality Water Temperature ■ Phase Type and Duration Enhanced Control System Enables Complex, Custom Test Programs Test Operation Easy to Understand Icons Simplify Navigation New icons make getting to the information you need ■ Large, Touch Sensitive Buttons

14 Factory Preprogrammed Test Methods The test list includes: ASTM Ford Space for Four Custom Test Programs Existing test methods can be copied and edited l soling vmXrt trmf Simplified Setup of Elective Control Features Set variance level notification for critical Multi-lingual Capability Select the desired language: Sample Management: ■ Operators can keep track of multiple tests within the same Weather-Ometer® right on the user interface. Up to 10 individual sample sets can be tracked at once, either by time or E-mail Notification: ■ Your Weather-Ometer can alert you by email when user...

LIGHT Long Arc Xenon is the Closest Simulation of UV, Visible and IR Solar Radiation Rotating Sample Rack The inclined rotating rack delivers the best exposure uniformity ■ Samples are rotated continuously during test. No need to manually rotate test samples specimen and chamber temperature, RH, irradiance and spray for even and consistent airflow over sample surfaces accommodate three dimensional samples – Small Components – Finished Products Intelligent Controlled Irradiance (Ci) System A closed loop system automatically adjusts lamp output in real-time delivering the most stable radiant...

Filter Combinations Inner Test Conditions Right Light Right Light CIRA Coated Quartz Soda Lime Cira on Type S Boro Type S Boro Quartz Quartz HL 35/65/4000 Soda Lime + Float Glass in Auxiliary Lantern Cira on Soda Lime + Float Glass in Auxiliary Lantern Type S Boro + 335 nm long pass filter in Auxiliary Lantern HL 3000/4000 Weathering tests requiring the most precise match to sunlight available Weathering tests requiring the most precise match to sunlight available and lower test specimen temperatures Most common combination for weathering tests (Daylight filter system) Most common...

CLIMATE CONTROL The Ci4000 Offers Thorough Climate Control to Best Replicate Your Materials’ End Use Environment Precise Humidity Control The electronic sensor provides direct and accurate measurements of relative humidity and enables automatic control at the specimen level ■ 10% * ependent on other parameters such D as lamp power, chamber temperature, ambient lab conditions etc. Specimen and Rack Spray Custom designed precision nozzle provides uniform spraying of samples with deionized water ■ The specimen spray applies water to the exposed surface of the sample which simulates rain to...

TEMPERATURE CONTROL Consistent, Controlled Temperature Delivers Repeatable and Reproducible Results SmartDamper ■ Balances test chamber temperature, BPT or BST and humidity levels and compensates for changes in ambient laboratory conditions chamber air, introduces ambient air or a combination of the two Black Panel Thermometer (BPT) or Black Standard Thermometer (BST) ■ Controls and monitors temperature at specimen level to ensure test repeatability of one sensor type while simultaneously monitoring the other Simultaneous Control of BPT/BST and CHT BPT/BST Temperature vs. Chamber...

OPTIONS Optional Features and Accessories to Extend the Capabilities of Your Next Weather-Ometer ® Hybrid Cooling System Improved xenon lamp cooling system dramatically reduces water consumption ■ Expanded LiquiAir options include onboard mounting * ependent on options, ambient lab conditions, D and test methods WXView ("Weather" View) Our new WXView data acquisition program allows users to archive test data or monitor conditions remotely in real time. ■ All standard test parameters such as rack temperature, chamber temperature, % RH and irradiance parameters such as lamp power, fan speed,...
