ATEX Zone 2, Split Unit Air Conditioners - 1

ATEX Zone 2, Explosion Proof Split Unit Air Conditioners Explosion Safety Atexxo Manufacturing BV converted Daikin to explosion safe ATEX split air conditioner unit, suited for zone 2 hazardous areas. The units have integrated heat pump function for both heating and cooling. The ATEX Air conditioners and ATEX split units are equipped with European approved R-410A refrigerant. ATEX Zone 2 is the European equivalent for US, NEC Class 1 Division 2 equipment. (C1D2) Conversion to ATEX explosion safe is in line with Atexxo’s philosophy of providing excellent explosion protection while maintaining as much features of the original product as possible. This makes the ATEX Air conditioners easy to install and operate. The sets consist of ATEX approved outdoor-, indoor unit and remote control. Versions with heating can cooling capacity ranging from 2 kW to 33 kW are available. (8.500 BTU/hr to 140.000 BTU/hr) Atexxo Manfacturing BV provides Explosion safe conversion for other leading European HVAC products and brands , like Carrier, Mitsubishi and Toshiba on request. Cost effective ATEX Zone 2 , split units. Benefits: Low noise unit (dB) Heat pump function for heating and cooling Easy to install and operate ATEX Zone 2 (Zone 22 on request) Ingress protection (IP) and impact tested Standard “Blue Fin” anti-corrosion treatment Gas tanker ships Chemical plants Offshore oil platforms Industry Harsh environments Analyzer / Battery rooms

Open the catalog to page 1

ATEX Zone 2, Split Unit Air Conditioners - 2

Safe operations in ATEX hazardous Zone 2 areas. Using multiple explosion protective measures to ensure safe operations in hazardous environments. Conversion to ATEX explosion safe is in line with Atexxo's philosophy of providing excellent explosion protection while maintaining all features of the original product. This makes the ATEX Air Conditioners easy to install and operate. ATEX Zone 2 is the European equivalent for US, NEC Class 1 Division 2 equipment. (C1D2) Protective Atex Safe Motor Tested Fan Assembly Modified Non-Sparking Motor The above picture demonstrates some of the...

Open the catalog to page 2

ATEX Zone 2, Split Unit Air Conditioners - 3

Input Voltage: Frequency : Type Split Unit : Refrigirant: ATEX: IIA / IIB / IIC 200-240 Volt 50Hz/60Hz Wall Mounted (Ceiling mounted on request) R-410A Zone 2, II 3G; ec ic nC h IIC T3 Gc ATEX Split Units Cooling Atexxo Manufacturing B.V. Atex Zone Capacity Order Number Heating SCOP Dimension indoor unit Dimension outdoor unit Capacity Ratio HxWxD (mm) HxWxD (mm)

Open the catalog to page 3
