Range of M pneumatic and mechanical machines Glossary: WCC: Welding Cabinet Controller EL: Effective Length ED: Effective Depth SS: Single Stroke cylinder DS: Double Stroke cylinder Manual adjustment: Adjustment is performed by a pressure regulator which determines the compressed air supply of the cylinder in order to obtain the best clamping force. Electronic adjustment: The adjustment of the welding force of the cylinder is controlled by a proportional valve. Pressure program: This device allows the pressure to be varied during the force, for example, to reduce it when welding or to...

ARO, world leader in rsistance welding, offers innumerable solutions for spot or projection welding applications, within the 50% of 30 kVA and 50 kVA power ranges. This new range of M machines, completely updated and redesigned, is structured around a single frame, with a choice of 2 pneumatic cylinders, 2 transformers and a range of 6 welding cabinet controllers (WCC). The user therefore has access to a wide range of possibilities to control better the welding current and the clamping force. The pneumatic M sries is equipped in standard version with a wide diversity of equipment such as:...

General characteristics: - 2 transformer powers: 30 or 50 kVA at 50%, - Standard voltage 400 V/50 Hz, - Cylinder clamping force at electrodes at 6 bars 740 daN, - Single stroke cylinder 100 mm, - or Double stroke cylinder 80+20 mm, - Effective depths at electrode axis, 350 or 550 mm, - Support stand for 550 mm electrode holder, - Machine equipped with standard electrode holder and a circuit breaker, - Effective spacing between arms from 59 to 374 mm (choice of 6 positions), - Machine completely cooled by water (transformer, secondary junctions, electrode holder and electrodes), - Welding...

MC type General characteristics: 2 transformer powers 30 or 50 kVA, Standard voltage 400 V/50 Hz, Delivered without electrode holders, 250 350 550 750 950 mm 870 590 358 257 200 daN - Effective depths according to choice of electrode holders Cylinder clamping force at electrodes at 6 bars Single-stroke cylinder 80 mm, or Double-stroke cylinder 60+20 mm, - Opening between electrodes adjustable from: 0 to 75 mm for an ED of 250 mm, 0 to 320 mm for an ED of 950 mm, - Machine equipped with standard electrode holders and a circuit breaker, - Machine completely cooled by water (transformer,...

MD type General characteristics: - 2 transformer powers 30 or 50 kVA, - Standard voltage 400 V/50 Hz, - Delivered without electrode holders, - Effective spacing between electrode holders from 174 to 489 mm (choice of 6 positions), - Effective depths according to choice of electrode holdersT250 I 350 I 550 I 750 I 950 mm - Clamping force between 150 and 400 daN for 250 mm standard electrode holders, - Automatic triggering of welding cycle when preset force is reached, - Machine completely cooled by water (transformer, secondary junctions, electrode holder and electrodes), - AR.01-type WCC,...

For MA - MC - MD machines 60 mm 0 mount UPPER AND LOWER ELECTRODE HOLDERS Effective length (C) References mm in 250 9.84 WK 110.300 350 13.78 WK 120.306 550 21.65 WK 140.303 750 29.53 WK 160.300 950 37.40 WK 180.300 Type of machine . MC, MD Electrodes can be installed indifferently in straight or inclined position. For inclined position, it is however recommended to limit the effective inter-arm spacing to 415 mm. Lower shank 350 550 13.78 21.65 WU 251.000 WK 120.305 WK 140.302 MA SETUP WITH ELECTRODE HOLDERS UPPER ELECTRODE HOLDERS Effective length (C) References Type of mm in machine 250...

For MA - MC - MD machines Cone No.3 STRAIGHT CENTERED ELECTRODES M. 303145 100.326 WL 303145 standard 23 mm WL 303156 long 34 mm WL 358156 with molybdenum insert WL 375155 with Cu-W insert WL 355145 electrolytic copper for light alloys (24 mm) WL 367156 long electrolytic copper for light alloys (35 mm) STRAIGHT EXCENTERED ELECTRODES WL 341145 standard 23 mm WL 342355 double excentered WL 341156 long 34 mm WL 304140 short 16 mm for two-pin electrode WL 359158 with molybdenum insert WL 381145 with Cu-W insert INCLINED EXCENTERED ELECTRODES WL 305145 standard 23 mm WL 305157 long 34 mm WL...

General characteristics: - 2 transformer powers 30 or 50 kVA, - Standard voltage 400 V/50 Hz, - Cylinder clamping force 740 daN at 6 bars, - Single-stroke cylinder 100 mm, - or Double-stroke cylinder 80 + 20 mm, - Platen dimensions 150 x 150 mm, - 2 slots center distance 63 mm, - Effective spacing of platens 133/223/313 mm, - Effective depth at cylinder axis 150 mm, - Machine completely cooled by water (transformer, secondary junctions, platens), - Welding current adjustment by constant phase shift or by adaptive adjustment according to choice of WCC, - Bi-manual control desk for SC or DC...

AR.01 AND 2X16III FUNCTIONS Many ARO WCC options and variants guarantee high-performance oprations in all types of applications. Secondary current adjustment, force control, program cascade are but some examples of the many functionalities proposed. This approach enables the complete series of M machines to accept a range of 6 different welding cabinet controllers. Industrial versions AR.01 5T2P 7T8P 10T16P 10T32P 10T16PEC Software versions 6A 6B 7A 7B 7E Number of programs 2 2 8 16 32 16 + 16 FUNCTIONS 1s squeeze 0 to 200 periods Squeeze 0 to 200 periods Welding 0 - 0.5 - 1 to 200 periods...

M type machines Column-mounfed lower lectrode holder for MA/MC/MD: This option allows continuous adjustment of lower lectrode holder height. Support stand for 350 mm electrode holder: Ensures rigidity of the assembly and allows precision welding. This option is strongly recommended when welding to quality charter. Manual pressure adjustment: In standard version on MA, MC and MB machines. Electronic pressure adjustment by proportional valve: This option allows the force to be stored in memory during the welding cycle from the WCC irrespective of the program used. Analog pressure sensor: This...

ARO The information and illustrations in this brochure are based on the technical characteristics of the products at the time when this document was printed. With the aim to constantly improve its products, ARO reserves the right to modify at all times the technical specificities of its products. This brochure includes information of a general character and is not a contractual document. The information in this brochure cannot be reproduced without express authorization from ARO SA. ai ■o ai E < o Q. ai o u
