Model AQIF AquaLink Water network efficiency AQ insertion flow sensor uses an improved Woltmann principle with electronic indication of turbine rotation. This innovation provides real-time feedback on turbine rotation, enabling improved accuracy and sensitivity, particularly at low flow rates. With the added benefit of integrated pressure and temperature sensing, our flow sensor provides comprehensive data for advanced process control. Flow Sensor, a cutting-edge solution designed to revolutionize water flow measurement. With its easy installation, calibrated per DN of the pipe, and ability to measure flow in both directions, pressure and temperature with equal resolution, this sensor provides quick and efficient water flow measurement. Whether you have plastic, metal or concrete pipes and require accurate measurements across various flow rates and pipe sizes, the AQ Flow Sensor is the ultimate choice. Our sensor is specifically designed to excel in drinking water applications, even in challenging environments with stones or small particles. With its robust construction and resistance to such impurities, the AQ Flow Sensor ensures reliable and accurate flow measurement. * Battery powered - 6 years lifetime * Bidirectional flow measurement * Installation under pressure (no stopping of water in the system) * Adjustable pulse output value * Accuracy less than 1 % (depending on measurements and margins conditions) * Integrated pressure and temperature * Possibility to service or calibrate the device Built- in GSM modem (GSM/GPRS/EDGE 900/1800, LTE-FDD B1/B3/B7/B8/B20, UMTS/HSPA +B1/B8) Or built- in Cat-M/Cat-NB/GPRS/EDGE modem (optional other) GPRS and SMS communication (configurable) to a AquaWeb server Accepts normal size SIM cards Bluetooth for on site programming (v4.2BR/EDR) Local connection trough USB cable (for initial configuration and troubleshooting) Installation length: AQ Link GmbH www.aq-link.de ■H Designed in Germany made in the EU

Water network efficiency AquaLink Flow Sensor Model AQIF Firmware features Configuration: • 2 way communication with AquaWeb server • Automatic Firmware update over internet or USB cable • All parameters can be configured remotely via internet Data sent during • Aqualink Idcommunication: • Rough location via GSM triangulation • Data logger readings • Battery voltage • GPRS/GSM signal • Firmware version • Device self power consumption • Inter(n)al humidity and temperature Configurable parameters: • Intervals of recording and transmitting of data • Mode for each input • Alarm thresholds (max. number...
