APV
Flex-Mix Liquiverter

Flex-Mix Liquiverter

Product catalog summary

Application
The Flex-Mix Liquiverter is designed for fast mixing of low to medium viscosity products, suitable for mixing, dispersion, recombination, and reestablishment of soluble products. It is used in the reconstitution of dairy products, manufacturing of fine foods, emulsions, and preparation of starch and hydrocolloid solutions.

Capacity
The equipment supports batch production up to 3000 liters, with a potential hourly capacity of up to 20,000 liters depending on the production plant.

Function
The Liquiverter features a square-shaped tank with a bottom-mounted high-speed mixing impeller that creates an axial flow, ensuring effective and homogeneous mixing. The design prevents forced rotation, creating a free vortex that aids in mixing powders and particles.

Technical Data
The document provides detailed specifications for various models, including tank volume, mixer impeller size, motor power, and weight. The models range from 250 to 3000 liters with different impeller sizes and motor specifications.

Standard Execution
All product-contacting parts are made of stainless steel AISI 316. The tank is available in sizes from 250 to 3000 liters, with options for heating/cooling jackets and insulation. The design includes a top-mounted manway cover, liquid inlets, and a bottom mixer outlet, with fittings according to ISO and DIN standards. The equipment supports CIP cleaning and features a sanitary design.

Design Features
The Liquiverter includes a directly coupled norm motor, double mechanical shaft seal, and options for special mixing impellers. It is designed for efficient operation with a focus on hygiene and ease of maintenance.

Contact Information
For further details, contact APV, an SPX Brand, in Silkeborg, Denmark, or visit their website for more information on worldwide locations and certifications.

Catalog excerpts

Flex-Mix Liquiverter

Open the catalog to page 1

2 Application The Flex-Mix Liquiverter is specially designed for products with low to medium viscosity in order to obtain a fast mixing of powders and particles with liquids. The Flex-Mix Liquiverter is usable for mixing, dispersion, recombination and reestablishment of soluble products. It is also used for reconstitution of dairy products, manufacturing of fine foods, emulsions, preparation of starch and hydrocolloid solutions. Capacity Up to 3000 litre – batch production. All depending on the type of production plant, the capacity per hour can be up to 20,000 litre. Function The Flex-Mix Liquiverter...

Open the catalog to page 2

Your local contact: APV, An SPX Brand Pasteursvej 1 8600 Silkeborg, Denmark Phone: +45 70 278 278 Fax: +45 70 278 330 For more information about our worldwide locations, approvals, certifications, and local representatives, please visit www.apv.com. SPX Corporation reserves the right to incorporate our latest design and material changes without notice or obligation. Design features, materials of construction and dimensional data, as described in this bulletin, are provided for your information only and should not be relied upon unless confirmed in writing. Issued: 07/2009 6206-02-07-2009-GB Copyright...

Open the catalog to page 4
