Reflow Oven Brochure - GF-120, 1800, & 2000 Series Reflow Ovens table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:9.00pt "Arial", sans-serif; } .font4 { font:10.00pt "Arial", sans-serif; } .font5 { font:23.00pt "Arial", sans-serif; } .font6 { font:46.00pt "Arial", sans-serif; } .font7 { font:14.00pt "Lucida Sans Unicode", sans-serif; } RTV Loose Radial Component Trimming System Spcifications: RTV Versatile Loose Component Trimmer The model RTV's standard tooling routinely processes a wide range of radial components including various capacitors, TO-92s, LEDs, SIPs, and most in-line radial devices. Its horizontal vibratory mechanism provides balance so top heavy components can be processed without falling. Cutting is performed by a true shear action between a serrated rotating cutting disc which grasps the leads, and a reaction blade which delivers a clean precise cut. Cut length is easily adjustable using a knob and a built-in scale. Processing speeds of up to 3,000 cph are typical. MIN (in) MIN (mm) MAX(in) MAX (mm) A 0.010 0.25 0.050 1.27 B 0.125* 3.17 0.625 15.88 C 0.125 3.17 2.000 50.80 D 0.030 0.76 1.375 34.93 E 0.030 0.76 0.750 19.05 F 0.040 1.02 4.000 101.60 *Shorter on request 115 VAC, 60Hz (other voltages available) W APS Novastar 2840 Pine Road Huntingdon Valley, PA 19006 镕 USA Phone: 215-938-1000 Fax: 215-938-1000 Օ www.apsgold.cominfo@apsgold.com © 2009 APS Novastar LLC Prices and Specifications subject to change without notice. LF002 200907 ADVANCED ASSEMBLՏ SYSTEMS
