Application Diagrams
The document details application diagrams for Blu-ray Disc players and receivers, focusing on the integration of audio components like HDMI outputs, audio DACs, and S/PDIF interfaces. Key components include CS4353 and CS4385 DACs, CS5346 ADC, and CS2000 timing solutions, crucial for high-quality audio output and synchronization.

Focus Products
The guide highlights Cirrus Logic products:

• CS5346 ADC: 103 dB dynamic range, 6:1 input MUX, programmable gain amplifier.
• CS4353 DAC: 106 dB dynamic range, 2 VRMS line-level outputs for stereo applications.
• CS4385 DAC: 8-channel output, 114 dB dynamic range for multichannel systems.
• CS49702 DSP: Supports high-definition audio formats and advanced processing, including Dolby and DTS.

Design Resources
Includes references to design resources and application notes on noise calculations, serial audio interfaces, and time-division multiplexed audio interfaces, aiding designers in optimizing performance and reducing costs.

Audio DSP Solutions
Cirrus Logic offers DSP solutions for Blu-ray Disc receivers, providing high-definition audio decoding and post-processing. The CS4970x DSP family supports various audio formats and features auto-update and auto-codec-switching for flexibility and future-proofing.

Clock Generation and Timing Solutions
The CS2xxx family offers clock generation and multiplication solutions, essential for low-jitter audio performance and effective synchronization of audio components.

Overview
Cirrus Logic provides resources to assist system designers in efficiently bringing audio product designs to production, including reference schematics, layout reviews, on-site engineering support, and software tools.

Legal and Warranty Information
Information is provided 'as is' without warranty. Customers should verify the latest information before ordering. Cirrus Logic disclaims liability for use in critical applications and requires indemnification if products are used in such scenarios.

Contact Information
Contact details for technical assistance are provided for North America, Asia Pacific, Japan, and Europe.
