Defense and Aerospace Solutions FEATURING APEX PRECISION POWER® TECHNOLOGY 2010 1 APPLICATION DIAGRAMS 5 PRODUCT GRADES, SCREENING PROCESS 7 MILITARY GRADE PRODUCTS, DSCC CERTIFICATIONS

CIRRUS LOGIC® | DEFENSE AND AEROSPACE SOLUTIONS 1 WWW.CIRRUS.COM Reducing the size and weight of aircraft electrical systems is always of paramount concern. Even the slightest reduction in the number of system components can provide a benefit. System reliability is also a critical factor to avoiding costly down time. Cirrus Logic products are designed into aircraft audio and noise cancellation systems for their reputation for high reliability, as well as for the high level of integration they provide inside a single, space saving package. These “off-the-shelf” solutions can be the best...

CIRRUS LOGIC® | DEFENSE AND AEROSPACE SOLUTIONS CIRRUS LOGIC® | D E F E NSE AND A EROSPAC E SOLUT IONS WWW.C IRRUS.COM 3 2 WWW.CIRRUS.COM Sonar Transducer Driver POA Application Product Type Product Model Sonar Linear Power Amplifiers PA02*, PA04, PA07*, PA08*, PA09*, PA10*, PA12*, PA73*, PA78, PA79, PA83*, PA84*, PA89, PA90, PA91, PA92, PA93, PA94, PA95 Power Boosters PB50, PB51, PB58 PIEZO TRANSDUCERS, DEFLECTION Cirrus Logic linear amplifiers, featuring Apex Precision Power technology, are designed into a wide range of piezo and deflection applications for their exceptional linearity,...

CIRRUS LOGIC® | D E F E NSE AND A EROSPAC E SOLUT IONS CIRRUS LOGIC® | D E F E NSE AND A EROSPAC E SOLUT IONS 4 WWW.C IRRUS.COM WWW.C IRRUS.COM 5 PRECISION VOLTAGE REFERENCES The Cirrus Logic 100 and 200 series of precision voltage references are zener-based references that offer either a single or dual output voltage. These are popular in systems where positive and negative reference voltages are required. Packaged in 14-pin DIPs and 20-pin LCCs, many are available with military process options (class H or K). Application Product Type Product Model Flight Control Actuators, Gimbal Controls...

CIRRUS LOGIC® | D E F E NSE AND A EROSPAC E SOLUT IONS CIRRUS LOGIC® | D E F E NSE AND A EROSPAC E SOLUT IONS 6 WWW.C IRRUS.COM WWW.C IRRUS.COM 7 PRODUCT GRADE BY SCREENING PROCESS The chart below outlines the static and dynamic test operations performed for the commercial/industrial, non-compliant “M” and fully-certified “M/883” compliant grades. In addition, the non-compliant “M” grade and fully-certified “M/883” are distinguished further by the DSCC certification which substantiates the level of quality screening required. Operation Commercial/Industrial Non-Compliant “M” /883 Compliant...

CIRRUS LOGIC® | D E F E NSE AND A EROSPAC E SOLUT IONS 8 WWW.C IRRUS.COM DSCC, ISO9001 QUALIFIED AND CERTIFIED PRODUCT BUILD FOR ALL GRADES Apex Precision Power product technology delivers high quality and reliability by using the same DSCC and ISO9001 (2008) certified and qualified manufacturing systems and processes across all product grades. Cirrus Logic Tucson is the design and manufacturing home of Apex Precision Power product technology and a DSCC certified and qualified QML-38534 facility. Certification has been maintained since November 8, 1989, and a QML listing as of May 31, 1990....

LEARN MORE AT www.cirrus.com CONTACT US For product selection assistance or technical support call the dedicated Apex Precision Power Application Engineers 800-546-2739, email apex.support@cirrus.com, or contact the Cirrus Logic office in your region. For a complete list of Cirrus Logic’s sales representatives and authorized distributors, please visit the Contacts area at www.cirrus.com NORTH AMERICA CORPORATE HEADQUARTERS 2901 Via Fortuna Austin, Texas 78746 United States T +1-512-851-4000 F +1-512-851-4977 Toll-Free +1-800-888-5016 CIRRUS LOGIC TUCSON 5980 N. Shannon Road Tucson, Arizona...
