1 – Round Die Products www.anchorlamina.com Check our website for the latest technical information.

6 Press Fit bushings have tapered holes, larger at press fi t end. This facilitates honing, since the bore will close up in a more nearly straight line when pressed in. While these bushings are precision fi nished on the O.D. a small amount of stock is left on the I.D. to allow for honing because they are pressed fi t type. Toe clamps and screws are not provided with press fi t shoulder bushings and they do not come with an LDSS grind. *Please note! D2 D1 L3 L4 L1 D3 .750 Grease Fitting SHOULDER BUSHING – PRESS FIT PART NUMBER NOMINAL PIN DIAMETER D1* D2 PRESS FIT DIAMETER D3 HEAD O.D. L1 OVERALL...

12 AUTOMOTIVE METRIC NAAMS STANDARD Evenly distributed graphite covers 20-30% of the sliding surface. Graphite is positioned to ensure overlapping in the slide direction. See page 18 for bore size information. NOTE: These pad bushings are made especially for automotive stamping companies. They conform to the standards agreed to by the North American Automotive Metric Standards group. A full complement of fl at products is also available from the Lamina Components line. SELF-LUBRICATING PAD BUSHINGS - NAAMS PART NUMBER D1 NOMINAL PIN DIAMETER D1 TOL c9 D2 WRING FIT DIAMETER D2 TOL g6 D4 L1 OVERALL...

18 DEFINITIONS OF MOUNTING PROCEDURES Pins and bushings require specifi c mounting procedures. By following these procedures the components should give maximum life and reduce downtime due to improper alignment, breakage and uneven wear. Pressed Fit – The component is installed in an interference condition: the bore size is smaller than the pressed fi t portion of the component. Bushings that require a pressed fi t should never be frozen or hammered. They should be forced into place using a hydraulic press or other proper tooling. Improper methods can permanently change the tolerance of the component....

33 Give us the opportunity to quote your specials. .. Quick turnaround time on round & fl at products (2 weeks on many) .. You get exact product you need .. Opportunity for innovation .. Call or e-mail for quote template Specials! Please send your prints to [email protected]!

34 L1 .188 D1 D2* .875 Lamina manufactures components specifi cally for use in dies where stripping operations take place such as in lamination dies. These components are made to “close tolerances.” STRIPPER GUIDE PIN BUSHINGS – BRONZE PLATED Assembly includes bushing, clamps and screws PART NUMBER Ground PART NUMBER *Unground Nom. Pin Dia. D1 D2 D3 D4 L1 L2 Bolt Circle Dia. No. "D" Clamps GCG-75 CG-75 3/4 .7503 .7502 1.1254 1.1252 1.125 1.313 1.625 1.000 1.719 2 GCG-100 CG-100 1 1.0003 1.0002 1.3754 1.3752 1.375 1.563 1.625 1.000 1.969 3 STRIPPER BUSHINGS – BRONZE PLATED PRESS FIT TYPE PART...

36 DIE LIFE REPLACEMENT RETAINING WASHER & SCREW KIT PART NUMBER R S T U V W DL75 .656 .490 .280 .585 .390 .330 PURPOSE Available as Replacement Part No. DL75 Die Life Retaining Washer. 6 per package. Includes fl at head socket screw 5/16-18x1. Note: In blanking die sections order optional Die Life “DL” Retaining Washers: Counterbore hole must be deeper. W Dia. U R Dia. T S V Radius d Counterbore b c REAM a g Counterbore in f stripping plate .187 h i j A p Travel .156 n B k C D E m 5/16-18 x 5/8 Socket Button Head Screw MODEL 75 HARDENED, GROUND AND VENTED Rockwell: RC 52-56 Case Hardened .015...

37 PART NUMBER A TRAVEL B LIFTER LENGTH C LIFTER POCKET D SPRING POCKET E SPRING FREE LENGTH F SLOT LENGTH REPLACEMENT DIE SPRING Lbs @1/10" SPRING DEFLECTION 112-50 0.50 2.812 2.625 3.063 2.50 1.250 12.0 112-75 0.75 3.062 2.875 4.063 3.50 1.500 8.0 112-1-0 1.00 3.312 3.125 5.063 4.50 1.750 6.4 112-1-25 1.25 3.562 3.375 6.063 5.50 2.000 5.5 112-1-50 1.50 3.812 3.625 7.063 6.50 2.250 4.5 112-1-75 1.75 4.062 3.875 8.063 7.50 2.500 3.8 M4L M6L M8L M10L M11BL M11CL PURPOSE Available as Replacement Part No. DL112 Die Life Retaining Washer. 6 per package. Includes fl at head socket screw 3/8-16x1-1/4....

38 5/16 -18 x .625 tap Rail & Screw Not Furnished .187 Optional: Tack Weld at As- .156 B G 5/16-18 x 5/8 Socket Button Head Screw A Travel a d Counter bore c REAM p n k F E C & D h PART NUMBER A TRAVEL B LIFTER LENGTH C &D LIFTER POCKET G E SPRING FREE LENGTH F SLOT LENGTH REPLACEMENT DIE SPRING Lbs @1/10" SPRING DEFLECTION T-750-50 0.50 2.312 2.500 1.187 2.50 1.000 4.5 T-750-75 0.75 2.562 3.500 1.437 3.50 1.250 3.0 T-750-1-0 1.00 2.812 4.500 1.687 4.50 1.500 2.5 T-750-1-25 1.25 3.062 5.500 1.937 5.50 1.750 2.1 T-750-1-50 1.50 3.312 6.500 2.187 6.50 2.000 1.4 T-750-1-75 1.75 3.562 7.500 2.437...

39 3/8-16 x 1” tap d Counter bore c Ream a Rail & Screw Not Furnished .250 Optional Tack Weld at Assembly A G Travel n .156 p B C & D k 3/8-16 x 1.00 Socket Button Head Screw F E h HEAVY DUTY RAIL STOCK LIFTER PINS MODEL 112T HARDENED, GROUND AND VENTED Rockwell: RC 52-56 Case Hardened .015 – .030 Deep Package complete with spring, screw and retaining washer. When ordering please specify: 1. Quantity 2. Catalog Number A – Operating Travel D – Pocket Depth for Spring B – Lifter Body Length E – Spring Free Length C – Pocket Depth for F – Slot length Lifter Body G – Top of Die to Top of Lifter Body...
