^ Lamina Hydraulic Motors www.anchorlamina.com j Check our website for the latest technical information. i

TYPICAL APPLICATIONS Hydraulic motors manufactured by Lamina have a main shaft that can be readily adapted by use of chuck or collet to hold tools for rotary machining operations, such as drilling, boring, reaming and the like. The unusual small size of these motors makes them a natural choice for many applications. • Chicken processing machinery • Reactor repair • Plastic Injection molding, thread core remover • Oil pipeline inspection equipment • Box sealing equipment • Tool manipulator, undersea, oil well • Camera manipulator, undersea • Camera manipulator, nuclear reactor • Drill and tap...

9/16-18 Tap No. 6 SAE Straight thread (2 Holes) 18° .6250 D. 404 Woodruff Key (on all shafts except 15CFM-K) 11/32 inch Diameter, (4 Holes) Spaced on a 5 hole pattern on 1.188 inch Radius 1-1/8 inches SHORT SHAFT FLANGE MOUNT To order specify: A25F, A37F, A50F, A62F, A100F, A125F 2-1/16 inches LONG SHAFT FLANGE MOUNT To order specify: A25FMO, A37FMO, A50FMO, A62FMO, A100FMO, A125FMO PEDESTAL FOOT MOUNT To order specify: A25FM, A37FM, A50FM, A62FM, A100FM, A125FM 3 All dimensions are shown in inches and are for reference only. Shaft Options (Standard shaft has no ordering suffi x.) 2 Flats on...

GEROTOR MOTOR A25 A37 A50 A62 A100 A125 DISPLACEMENT (cubic inches per revolution) 0.82 1.16 1.53 1.88 3.11 3.73 GEROTOR SIZE (Inches) 0.250 0.375 0.500 0.625 1.000 1.250 CAPACITY (Maximum GPM) 8 8 8 8 8 8 SPEED (Maximum RPM) 2255 1592 1206 982 595 495 TORQUE (Maximum Inch-pounds) 149 222 284 363 570 656 MAXIMUM SIDE LOAD (pounds-force) 300 300 300 300 300 300 MAXIMUM PUSH FORCE (pounds-force) 500 500 500 500 500 500 MAXIMUM PULL FORCE (pounds-force) 300 300 300 300 300 300 Sample Motor Weights (pounds) F Standard Flange - Short Shaft 3.55 3.55 3.55 3.60 3.80 3.90 FMO Standard Flange - Long Shaft...

7 HYDRAULIC MOTOR COMPONENT PARTS Item No. PART NUMBER PART DESCRIPTION NOTE Item No. PART NUMBER PART DESCRIPTION NOTE 1 BSS-1 Blood Slinger Shield Optional Seal - order separately 12 15CFMK Motor Shaft with Key FMO only-3/16 x 1-1/4 Key 2 48CF Dirt Seal All motors 13 13CA-1/4 Spline Drive A25 motors only 3 60CFM Foot Mount FM style motors only 13 13C Spline Drive A37, A50, A62, A100, A125 only 4 52CFM Shaft Bearing FM style motors only 14 11CF Motor Body All motors except Aluminum 5 62B Screw (10-32x1/2) All motors - 5 required 14 11CF-ALUM Motor Body Aluminum 6 50C Copper Washer Seal All motors...

Committed to Quality & Customer Satisfaction Anchor Lamina is committed to be the “customer focused” worldclass supplier of choice to the metal-working and plastics forming industry. We will help our customers to compete globally by providing innovative and value added products and services. Lamina warrants our hydraulic motors to be free from defects in material and workmanship. The warranty period lasts until 6 months from the date of shipment. Any modifi cations made to the motor will void the warranty. For full warranty details, please go to http://www.anchorlamina.com/termsofservice.html....
