3 Lamina, Inc. began as a lamination die manufacturer in 1938. During the years from 1938 to the present Lamina has evolved into a manufacturer and distributor of die and mold components. Even though we no longer make dies, we do understand the die and mold maker’s needs and objectives. We have made it our business to supply quality products in a timely manner at a reasonable price. We know how to compete in the marketplace and supply you with the products you need when you need them. With the introduction of this catalog featuring sliding guide components for molds, machinery and dies, we...

7 L-GIBS – METRIC – SOLID BRONZE – SELF-LUBRICATING PART NUMBER L W A GH B GW C D E F G H J K QUANTITY M & S +0.00 Size –0.13 +0.025 –0.000 +0.00 –0.13 ±0.127 M S L15LG100G 100 32 15 10 30 22 11 20 - - - 60 2 - M10 L15LG150G 150 - 55 - 55 3 - L15LG200G 200 55 - 50 55 4 - L15LG250G 250 70 - 70 70 4 - L25LG200G 200 50 25 22 45 28 14 55 - 50 55 - 4 L25LG250G 250 70 - 70 70 - 4 L25LG300G 300 65 65 65 65 - 5 L25LG350G 350 80 75 75 80 - 5 Drilled & Counterbored Holes See “S” F Start G Typ. H J K D E Typ. L Drill through for M10 Screw (See “M”) W C A B Precision machined sliding surfaces Unless...

9 GIB ASSEMBLIES – INCH ASSY. WITH T-SLIDE PART NUMBER ASSY. WITHOUT T-SLIDE PART NUMBER L W +.000 –.005 A B +.001 –.000 C1 D E H Socket Head Cap Screws Locating Dowel Pins No. Holes Size No. Holes Size L2GA16GTS L2GA16G 2.00 2.620 1.12 .312 1.12 1.50 .75 1.63 4 L2GA24GTS L2GA24G 3.00 4 1/4-20x1-1/4 4 1/4 x 1-1/2 L2GA32GTS L2GA32G 4.00 6 L3GA24GTS L3GA24G 3.00 3.120 1.12 .375 1.12 1.62 .75 1.62 4 L3GA32GTS L3GA32G 4.00 6 5/16-18x1-1/2 4 1/4 x1-1/2 L3GA40GTS L3GA40G 5.00 6 L4GA24GTS L4GA24G 3.00 4.120 1.25 .500 1.62 2.37 .88 1.75 4 5/16-18x1-1/2 4 1/4 x1-1/2 L4GA32GTS L4GA32G 4.00 6...

11 Optional T-Slide for Gib Assemblies – Inch The inch-sized T-Slide is often used as a Lifter Slide and can be purchased separately or as a part of the gib assembly. PRODUCT FEATURES High quality carburized steel NOTE: See page 9 for complete assembly. T-SLIDE FOR GIB ASSEMBLIES – INCH Part Width B C C/2 Height Number W (in) (in) (in) (in) H (in) 2GASLIDE 1.493 0.308 1.110 0.555 1.25 3GASLIDE 1.617 0.371 1.110 0.555 1.25 4GASLIDE 2.367 0.496 1.610 0.805 1.38 6GASLIDE 2.617 0.746 1.610 0.805 1.75

15 WEAR STRIPS – INCH – BRONZE-PLATED – SELF-LUBRICATING PART NUMBER T Thickness +.000 –.002 W Width +.000 –.060 PART NUMBER T Thickness +.000 –.002 W Width +.000 –.060 PART NUMBER T Thickness +.000 –.002 W Width +.000 –.060 By the inch 48 length By the inch 48 length By the inch 48 length SLFP025-100 SLF025100 1/4 1 SLFP050-100 SLF050100 1/2 1 SLFP100-100 SLF100100 1 1 SLFP025-150 SLF025150 1-1/2 SLFP050-150 SLF050150 1-1/2 SLFP100-150 SLF100150 1-1/2 SLFP025-200 SLF025200 2 SLFP050-200 SLF050200 2 SLFP100-200 SLF100200 2 SLFP025-250 SLF025250 2-1/2 SLFP050-250 SLF050250 2-1/2 SLFP100-250...

19 Aluminum Bronze with Self-Lubricating Graphite Plugs Wear Strips – Inch – Fixed-Length A B C D E F L G W For “N” Screws T A B C L G H W A B C D E F L G H W RECOMMENDED MOUNTING SCREW SIZES THICKNESS N 1/4 1/4 Flat head screw 3/8 1/4 Socket head cap screw 1/2 5/16 Socket head cap screw 5/8 5/16 Socket head cap screw Material: Aluminum Bronze All Dimensions ±.010 unless noted Mounting hole patterns for Wear Strips When ordering please indicate preference at the end of the part number: G Drilled with Graphite Example: L212-32G NG Undrilled with graphite Example: L212-32NG Bronze with...

21 Wear Plates – NAAMS Series W05, W06 & W07/VDI 3357 – Metric MATERIALS: Self-lubricating wear plates are manufactured from aluminum bronze or steel with graphite plugs. The plugs cover 20-25% of the wear surface. Wear plates are also available in plain steel. Wear plates are also available in the GM sizes in cast iron with graphite. See the cross reference sheet on pg. 23 for the GM part number. TOLERANCES: Thickness ± 0.00/ -0.02 mm Mounting hole locations ± 0.2 mm Flatness ± 0.013 mm Unless otherwise noted ± 0.25 mm MOUNTING SCREWS: M8 S.H.C.S. for part numbers VDY050080 and VDY080050....

27 CORNER GUIDE BLOCKS – METRIC PART NUMBER H A B C D L ±0.25 ±0.013 ±0.013 ±0.25 G118007 75 G118010 100 25 35 40 55 80 G118012 125 G119507 75 G119510 100 40 50 55 70 95 G119512 125 G111207 75 G111210 100 65 75 80 95 120 G111212 125 Corner Guide Blocks For M16 Soc. Hd. Screw (2) Holes ø16 G6 (2) Holes -B- -AL D B H 25 32 Surface Harden & Graphite Plug Cross-Hatched areas 6 x 45° Chamfer A L C 10 0 20 T 0.025 B 0.8 0.8 T 0.025 A 0.8 NOTES & SPECIFICATIONS Screw hole locations ±0.25 Dowel hole locations ±0.10 Apply a fi lm or mist of light machine oil on new self-lubricating parts before use...

29 Guide Blocks – Inch, continued C 1.00 1.26 .67 .50 A D L for 1/2 S.H.C.S Spot Drill (farside) for 1/2 dowel 3/8-16 Tap (2) for Jack Screws (not on 3 part) C 1.00 B 1.26 .88 .67 .50 D L H +.000 –.010 1.875 This surface is hardened and has self-lubricating graphite plugs +.000 –.010 C B A 1.00 1.26 .67 .50 D L 4-HOLE PATTERN TYPICAL SECTION Guide and Keeper Blocks are used together for guidance and alignment. Keeper Block information starts on page 32. Note: Mounting Hole locations ±.005 2-HOLE PATTERN 3-HOLE PATTERN

33 Keeper Blocks – Light-Duty, continued L D A .50 for 1/2 S.H.C.S. for ø17/32 Spot Drill C for 3/8-16 Jack Screw A 1.00 .59 1.44 L F A A .50 .59 1.44 1.00 C D E H K 1.94 .250 J This surface is hardened and has self-lubricating graphite plugs Keeper Block as Side Guide FOR 8 TO 10 INCH LENGTHS TYPICAL SECTION A–A FOR 3 AND 4 INCH LENGTHS FOR 5 AND 6 INCH LENGTHS L E A A C D .59 .38 1.44 .50 1.00 ±.005

35 Keeper Blocks – Medium-Duty, continued L C .50 A 1.06 1.88 .62 D A for 1/2 S.H.C.S. ø17/32 Spot Drill H K 2.38 .250 J This surface is hardened and has self-lubricating graphite plugs .50 1.06 1.88 .62 C D E A A L F L E A A 1.06 .50 1.88 .62 C D L F .50 1.06 1.88 .62 C D E G A A For 3 Inch Length Typical Section A–A For 4 to 6 Inch Length For 8 Inch Length For 10 Inch Length ±.005
