All coils feature: Heat resistant bobbin moulded with 30% glass filledthermoplastic polyester materialՕClass H200C wire according to IEC317-8 ЕBuilt-in magnetic yoke made by low carbon iron Encapsulation with high quality custom designed glassfilled nylon or thermoplastic polyesterThe use of other materials is possible upon special agree- ments. All coils are rated to Class F and IP65 (with connector and suitable seals) and for continuous service. These coils are designed in accordance to EN60204.1 and VDE0580 and are in conformity with 73/23EEC directive. AmiscoՒs EVI3 coils cover all the most...

TYPE 3E= EVI3E3P= EVI 3P 3D = EVI3D COIL BORING 13 = 13 mm 14 = 14 mm 16 = 16 mm 19 = 19 mm ELECTRICAL CONNECTION A = AMPJunior C= Flying leads D = DIN43650 A K = KOSTALM27x1 T = Deutsch DT04 integrated S = Superseal integrated M = Metripack 2 integrated SUPPLY CURRENT A= Alternating current (A.C.) D= Direct current (D.C.) R = Rectified alternating current (R.A.C.) NOMINAL VOLTAGE Example:024 = 24V220 = 220V WINDING CODE To be communicated by AMISCO SPECIAL FEATURES E MARKING ZN= Standard marking (nominal voltage) XX= Customer marking Alternative possibilities > for CUSTOMER LOGO size="-1">

Coil suitable for hydraulic applications.It can be supplied with different power consumptions according to specific requirements.Available with different types of electric connections. (seeside page).TECHNICAL DATAStandard Power consumption: 21W /28VA Force: see the graph Duty Cycle: 100% ED (continuous) Standard operating voltages: 12-24 VDC 24-110-220 VAC Other voltages on request. Operating voltage range: max: 10% over the nominal voltage. min : according to the specific application. Operating temperature range:-30C з+50CDegree of protection: IP 54 (EN 60529 ) With connector and suitable seals...

TECHNICAL DATAStandard Power Consuption: 26W /35VA Force: see the graph Duty Cycle: 100% ED (continuous) Standard operating voltages: 12-24 VDC 24-110-220 VAC Other voltages on request. Operating voltage range: max: 10% over the nominal voltage. min : according to the specific application. Operating temperature range: -30C з+50C Degree of protection: IP 54 ( EN 60529 ) With connector and suitable seals it can reach IP 65 (DIN version). Coil insulation: Class FGENERAL CONSTRUCTION: According to EN 60204.1 and DIN VDE 0580 MATERIALS: Wire class H200аC, Encapsulant: glass filled PA 6-6 or glass...

Force - stroke curve Stroke (mm) 8070605040302010 > Force (N) TECHNICAL DATAStandard Power consumption: 21W /28VA Force: see the graph Duty Cycle: 100% ED (continuous) Standard operating voltages: 12-24 VDC24-110-220 VACOther voltages on request. Operating voltage range: max: 10% over the nominal voltage. min : according to the specific application. Operating temperature range: -30C з+50C Degree of protection : IP 54 ( EN 60529 ) With connector and suitable seals it can reach IP 65 (DIN version). Coil insulation : Class F > 1 0,20,51,522,53 Force-stroke curve at Ж10% nominal voltage and stabilizedduty...

DIN 43650A FLYING LEADS DIN 43650A FLYINGLEADS >

s.p.a. Via Piaggio, 70 - 20037 Paderno Dugnano - Milano - ItalyTel.: 0039-02.99.00.181 - Fax: 0039-02.99.00.18.60http://www.amisco.it - e-mail: [email protected] >
