TEQUATIC™ PLUS F-150 Filter, TEQUATIC™ PLUS F-150 Filter, C-Series Skid ||Product Data Sheet Skid Product Data Sheet Designed for Nasty Water The TEQUATIC™ PLUS F-150 Filter, with its innovative and patented design, combines the power of continuously cleaning, cross-flow filtration with forced settling and solids collection into a single device. The fouling resistant filter element delivers a consistent level of solids removal down to 10µ while processing a wide range of extremely nasty, highly loaded, difficult-to-treat water. The unique cross-flow action, combined with an engineered, laser-cut filter element, delivers the highest possible flow and maximum solids separation without constant plugging or forming a filter cake layer. See operational details on page 3. Other key advantages include: • Operates consistently and reliably where other filters can Industries Served The TEQUATIC™ PLUS F-150 Filter is an outstanding choice for removing difficult solids in a variety of commercial and industrial wastewater treatment and reuse markets, such as: • Oil and gas, including refinery water • Agriculture, rinse and wash water • Cooling towers • Food and beverage (e.g. meat processing, brewery, and fail, on fluid streams containing some or all of the following: - High TSS: 100-10,000+ mg/L - Fats, oils, and grease (FOG) - Long or short fibers - Hair, lint, and algae • Simple, self-cleaning, automatic operation • Compact footprint (e.g. less space, waste, chemicals, air) • Operationally efficient: - Low maintenance and high uptime – no backwashing or excessive filter changes • Livestock production - High water recovery: up to 99% • Municipal wastewater treatment and reuse - Energy efficient (0.25-2 psi pressure drop across the filter) • Plastics recycling • Pulp and paper • Textiles and laundry The C-Series Skid: Proven, Fast, Easy The TEQUATIC™ PLUS F-150 Filter C-Series Skid is built and tested with your needs in mind. Key benefits include: Application Examples • It is designed for fast “out of the box” installation and • Reliable and proven skid design simplifies and optimizes to eliminate or reduce waste discharge fines and/or surcharges • Pretreatment or cost-saving alternative to clarification, DAF* and aeration • Pretreatment to downstream membranes and filters - Protect MF, UF, RO, and other membranes - Reduce bag and cartridge filter change-outs - Decrease backwash cycles in media filters • TSS reduction in oilfield water applications: - Protect disposal wells - Facilitate reuse of frack flowback water startup, and easy serviceability. performance, in a compact footprint. • Scalable modular configuration; each skid can connect in parallel to a common feed manifold to meet required flows. • Innovative control system runs, monitors, and logs essential parameters. • Touch screen interface allows for customization of timers and set points to any industrial setting. • Designed for waste treatment applications with total suspended solids up to 10,000 PPM; 30-80% removal efficiency of 10-17 micron particles, 80-90% of 1845 micron particles, 95% or greater removal of particles 45 micron and larger. *BOD = biological oxygen demand; COD = chemical oxygen demand; TOC = total organic carbon; DAF = dissolved air flotation; FOG=fats, oil, and grease; UF = ultra

Standard Features Equipment • Chrome-plated 316L SS filter element • Fiberglass filter housing • Corrosion-resistant internal components are HDPE, PC, SS 316, with Viton™ O-rings • Advanced polymer cleaning assembly • Schedule 80 CPVC, high-temperature piping • Powder-coated carbon steel frame • 5 HP recirculation pump with integrated PLC and VFD • Automated motor-actuated valve for purge with feedback • Optional CIP system for water with high levels of FOG • Filtrate flow control valve automated for quick self- contained tuning as process water fluctuates • Valves for isolation, drain, and...

TEQUATIC™ PLUS F-150 Filter Operation As shown in the illustration to the right, operation of TEQUATIC™ PLUS F-150 Filters is simple yet effective. 1. Pressure-controlled feedwater enters the unit and the water velocity across the filter screen initiates cross-flow filtration. The feedwater flow drives the cleaning brush assembly, activating the cleaning mechanisms within the filter which continuously clean the filter screen, minimizing cake buildup. Solids enter the recirculation and solids collection chamber. Heavy solids remain in the collection chamber while other particles flow into...

Control System Capabilities The control system for the TEQUATIC™ PLUS F-150 Filter C-Series Skid is a PLC-based processor (Siemens S7-1200) which automatically manages and monitors all critical system functionality. The HMI (Siemens TP700) touch screen allows for simple customization of timers and set points to specific needs, and controlled access to set points is operator level and passcode protected. Automatic control, shutdowns and alarms are incorporated. Equipment incudes ethernet communication hardware capabilities to communicate with plant SCADA systems or to set up remote...
