ATI Radeon™ E4690 Embedded Graphics Processor Serious Graphics for Gaming and HD Video Unprecedented Embedded Graphics Performance The ATI Radeon™ E4690 delivers leading performance for embedded applications from casino and arcade gaming to digital signage. With 3x the performance of AMD's previous generation embedded GPUs*, the E4690 can help deliver the performance needed for today’s embedded applications. This performance is delivered through state of the art features, including a wider 128-bit memory interface and 512MB of on-chip memory. The E4690 provides broad hardware support for video codecs and allows for multiple HD video streams to be decoded simultaneously delivering features like picture in picture. For ultimate performance, multiple GPUs can be combined through ATI CrossFireX™ technology. Low and Scalable Power Consumption Based on 55nm technology, the E4690 delivers more than double the performance per watt* than previous generation processors. Built with ATI’s PowerPlay™ technology the E4690 has dynamic power management delivering high performance when needed, while intuitively conserving energy at idle or when demand is low. The E4690 graphics processor also allows for exceptional scalability of performance between 8W and 25W. >> Desktop-level Performance> - 320 shader processors - 128-bit memory interface - 512 MB GDDR3 Broadest Range of Display Outputs Today’s embedded applications require support for a large range of output interfaces. The E4690 delivers a comprehensive selection of output options including the first ever embedded support for DisplayPort that delivers up to 2x the bandwidth of DVI. Whether it is HDMI, dual-link DVI, analog output, or custom timings for LVDS panels, the E4690 has the flexibility to meet most embedded applications. >> Exceptional Video Decode> - H.264, VC-1, MPEG-2 - Picture-in-Picture Assurance of Availability AMD understands the unique requirements of the embedded market. Unlike desktop PC solutions, embedded designers need to know that the high performance graphics processors they select today will be available in years to come. That is why as with other AMD embedded graphics solutions, the E4690 has a five year supply availability. >> Extended Availability> - 5 year supply availability** - Dedicated technical support Fast Time to Market AMD embedded graphics products focus on speeding your solution to market by simplifying the design and providing specialized technical support. By incorporating the high-speed graphics memory on-chip, the E4690 helps simplify board design. During all phases of design, development, and deployment, AMD works with designers to deliver support from technical experts that can help to solve issues and allow their customers to spend more time focusing on the features that make their solutions unique. ATI Radeon™ E4690 Performance ATI Radeon™ E4690 Scalable Performance 3DMark06 HDR/SM3.0 8W E4690 150e/250m1 17W 25W 784 E4690 300e/400m E2400 450e/600m E4690 600e/700m 12W 0 1425 2161 2669 500 1000 1500 2000 2500 3000 Note 1. e/m indicates the 3D engine (e) and memory (m) clock speed in MHz. * Performance claim based on 3DMark06 HDR/SM3.0 benchmarks compared to the ATI Radeon E2400. ** Part availability is planned for 5 years from date of announcement, subject to change without notice.

Open the catalog to page 1

ATI Embedded Comparison E2400 E4690 600 MHz 600 MHz 65nm 55nm PCIe 1.1 (x1, x2, x4, x8, x16) PCIe 2.0 (x1, x2, x4, x8, x16) 40 320 Graphics Processing Unit Max Frequency Process Technology CPU Interface Shader Processing Units AVIVO Display Engine Full 30-bit Display Pipeline DirectX 10 10.1 Shader Model 3.0 4.0 OpenGL 3.3 3.3 H.264, VC-1 H.264, VC-1, MPEG-2 700 MHz 700 MHz Type GDDR3 GDDR3 Configuration (on-chip) 128MB 512MB Width 64 bit 128 bit Analog RGB (triple 10 bit DAC, 400MHz) 2 2 Analog TV (YPbPr, Composite, SVideo) 1 1 DVI – Single Link 2 2 DVI – Dual Link 1 2 Stream Computing...

Open the catalog to page 2
