igLOO SERIES HEATING COOLING CIRCULATORS

About AMAR Serving industry since 1974 50000 sqft state-of-the-art manufacturing facility Largest manufacturer of heating cooling circulators in India Largest manufacturer of pressure & flow reactors in India Well equipped flow chemistry process developed lab Unmatched quality & safety standards Manufacturing on CNC-VMC & automated machines Prompt & efficient after sales service Highly skilled & trained team of more than 250 personal Our VISION To be a globally leading provider of innovative, cutting edge products and services, thus empowering clients to achieve enhanced efficiencies, sustainability...

Heating Cooling Circulator PROCESS / BATH TEMP BATH TEMP PUMP ON/OFF HEAT TRANSFER SPECIALIST COMP ON/OFF HEATER ON/OFF OVER TEMP CUTOFF ambiTHERM ambiTHERM igLOO SERIES SALIENT FEATURES • • • • • • Closed Loop Thermostats: -90 °C to 250 °C. Open Bath Thermostats: -70 °C to 175 °C. High Temperature Thermostats: Ambient to 350 °C. Recirculating Chillers: Up to -15 °C. CE marked units & refrigerant optional With accurate programmable temperature controller & touch panel • High performance & energy efficient systems. • High pressure booster pump for flow reactors. • Ex-proof systems for hazardous...

SALIENT FEATURES • Temperature range: -90°C to +250°C • Temperature controller type: PID cascade control • Temperature display: Touch screen display • Temperature control type: Jacket 8 / or process • Temperature control accuracy: ±0.5°C • Heating: Electrical heating • Cooling: Refrigeration system (CFC free refrigerants) • Body M.S. Powder coated 8 Media touching parts SS-304 • RS 485 communication port with SCADA software • Multistep ramp soak programmable controller • Data logging / recording optional • Mounting on suitable caster wheels • Suitable chillers for water cooled machines 04 HEAT...

• The given cooling power is at 25°C ambient temperature. Increase in ambient temperature will affect performance of machine • Suffix "W" in model is for water cooled machines • The temperature range mentioned above is at outlet of the machine hence temperature inside the process / load may vary due to various factors like process design, distance, head, insulation etc. • *Pump flow rates are at atmospheric pressure • Since development is continuous process, the above specifications are subject to change without prior notice. HEAT TRANSFER SPECIALIST 05

SALIENT FEATURES • Temperature range: -70°C to +175°C • Temperature controller type: PID • External load and bath temperature controller • Temperature control accuracy: ±0.5°C • Heating: Electrical heating • Cooling: Refrigeration System (CFC free refrigerants) • Body M.S. Powder coated 8 Media touching parts SS-304 construction • RS 485 communication port with SCADA software • Multistep ramp soak programmable controller • N2 purging facility to prevent fuming • Mounting on suitable caster wheels HEATING COOLING BATH: -25°C to +175°C • Oil performance in Bath circulators can vary depending on...

• Temperature range: ambient to +350°C • Temperature controller type: PID • External load and bath temperature controller • Temperature control accuracy: ±0.5°C • Heating: Electrical heating • Cooling: Through internal cooling coil • Body M.S. Powder coated 8 Media touching parts SS-304 construction • RS 485 communication port with SCADA software • Multistep ramp soak programmable controller • Optional: N2 purging facility to prevent fuming • Mounting on suitable caster wheels HIGH TEMPERATURE CIRCULATOR: AMBIENT TO +350°C * Control panel dimensions: 300 x 300 x 300 HEATING BATH: AMBIENT TO +175°C...

IGIOO Series IGLOO Series • The given cooling power is at 25°C ambient temperature. Increase in ambient temperature will affect performance of machine • The temperature range mentioned above is at outlet of the machine hence temperature inside the process / load may vary • *Pump flow rates are at atmospheric pressure a. Synthetic heat transfer fluid for wide temperature range (non toxic 8 non flammable) b. SCADA software for PC operated / programmable heating or cooling machines with online 8 historical data Logging. c. Flexible SS hose pipes with insulation for fluid circulation d. Purge panel...

• Suffix "W" in model is for water cooled machine • The given cooling power is at 25°C ambient temperature • The temperature range mentioned above is at outlet of the machine • Custom built models on request, as per process requirement • HTC series, machines with higher heating capacity S ex-proof version on request • *Pump flow rates are at atmospheric pressure

^ aether elementally innovative -Touching Lives over'j(^^) A memeber of Lalbhai Group Committed to healthier life! •V Dr. Reddy’s <DUPONT* £isai ^^nrmenict] * for good, naturally rGMM-11— Pfaudler J The Transparent specialist t*£ipca * A dose of life * Global Supplier of Fine and Specialty Chemicala 10 HEAT TRANSFER SPECIALIST Johnson Matthey LARSEN &TOUBRO

OUR VALUED CLIENTS J. LUPIN PHARMACEUTICALS, INC. performance materials Piramal Healthcare knowledge action care Polymer Technologies International Industries Limited make it better together eO MAKING OUR NATION PROUD ar|BcW in <?xrwfttry iroMittre.- Cllw Syngene ^ Blocon company syngenta TATVA CHINTAN THEMIS MEDICARE Imagine. Innovate CREATING POSITIVE REACTIONS HEAT TRANSFER SPECIALIST

09/24 Copyright @2024 Amar Equipment Pvt. Ltd. AMAR EQUIPMENT PVT. LTD. Valson Compound, LBS Road, Bhandup (W), Mumbai - 400078, INDIA. +91-22- 6225 5000 [email protected] / [email protected]
