Screening Crushing Mixing Aerating Loading ALLU SC -Series Screener Crushers www.allu.net

“ALLU Screener Crusher simultaneously screens, crushes, aerates, mixes and loads different kinds of materials” ALLUizing makes sense Alluizing is a quick and cost-effective method for processing different materials. ALLU has developed a working method called Alluizing. It means that ALLU Screener Crusher processing attachment screens, crushes, mixes, aerates and loads different kinds of materials simultaneously in a quick and economic way. The new ALLU SC does the Alluizing more efficiently than ever. With an ALLU Screener Crusher processing attachment you can convert your base machine into a...

• For excavators from 8 to 25 tonnes • For wheel loaders from 5 to 14 tonnes • Maximum continous hydraulic power 60 kW • Economic choice for basic applications and smaller base machines • For excavators from 20 to 34 tonnes • For wheel loaders from 12 to 24 tonnes • Maximum continous hydraulic power 80 kW • For excavators from 22 to 40 tonnes • For wheel loaders from 13 to 26 tonnes • Maximum continous hydraulic power 140 kW • Dual power transmission with two motors • Heavy and extra heavy applications • Medium heavy and heavy applications ALLU SC Screener Crusher

ALLU Screener Crusher features The properties of the ALLU Screener Crusher SC–series make it suitable to applications, requiring utmost durability and efficiency. The construction is lighter than before, however, mechanically stronger and servicefriendly. 1. Innovative frame design 3. No need for drain oil line • Straight outer sides • Low fastening points for wheel loaders • Lower installation costs • Easy to use on different base machines 4. Built-in power adjustment valve • Ensures tight fastening for the adapter • Fastening points are part of the rigid frame construction ALLU SC Screener...

ALLU SC Screener Crusher accessories Guide Plate Crushing Bars Prevents exiting material from spattering against the loader. Guide plate is also a fixing point for other accessories Crushing bar accessory is developed in order to increase the crushing effect of the bucket. Extra Sides Helps to mix clay products, because the material will circulate from drum to drum before exiting. The mixing plate always needs the guide plate. Extra sides are available to increase the volume of the bucket. Extra sides are always recommended for wheel loader applications. Electric Directional Valve Frame has a...

• Disc distance 20 mm, 35 mm or 55 mm • XHD 35&55 disc thickness 10 mm • High wear resistance • Made for heavy duty use • Changeable blades • Excellent mixing and pulverising capability combined with crushing effect • Clog-proof construction even with wet and sticky materials • High processing capacity • Production of soil • Backfilling of pipeline trenches • Processing demolition waste, crushing of bricks or glass • Aerating compost • Mixing and stabilising of bulky materials • Pre- and coarse screening, pulverising • Aerating • Crushing Blades for drums SC 35 & 55 Universal blade for most applications...

ALLU SC Series selection table In the enclosed table you will find the suitable ALLU Screener Crusher to your base machine. The weight classes for excavators are 8-40 tons and for wheel loaders 5-26 tons. Base machine weight recommendation tn Hydraulic oil flow requirement Min - Max l/min Volume water / heap ISO / SAE m³ Max hydr. power Cont./peak kW Weight incl. 55 XHD drums kg 8 - 40 tn EXCAVATORS & BACKHOE LOADERS SC 2-10 SC 2-15 SC 2-20 SC 3-10 SC 3-15 SC 3-20* SCH 3-15 SCH 3-20* SCH 4-15 SCH 4-20* SCM 3-15 SCM 3-20 SCM 4-15 SCM 4-20 5 - 26 tn WHEEL LOADERS & BACKHOE LOADERS SC 2-15 SC 2-20...

ening, crushing, mixing, aerating, ading in one step operation ALLU Stabilisation System Mixing soil and binding agent in mass ALLU Compac High power compacting plates for Mixing and aerating different m from compost to contaminat Email: [email protected] Email: [email protected] ALLU Deutschland GmbH Email: [email protected] ALLU Sales office China Email: [email protected] ALLU France S.A.R.L Email: [email protected] ALLU South America Email: [email protected] ALLU Group 700 Huyler Street, Teterboro, Email: [email protected]
