Tanks brochure

Product catalog summary

Overview: Allegheny Bradford Corporation specializes in the fabrication of custom stainless steel tanks, utilizing high-quality materials such as type 304, 316, and 316L stainless steel. The company ensures compliance with stringent industry standards through rigorous testing and documentation throughout the manufacturing process.

Specifications: The tanks are certified with ASME Code Stamping and National Board Registration, TUV Certification, and Canadian Registration. They are designed to withstand a Maximum Allowable Working Pressure (MAWP) of 150 PSI at 300°F and a Minimum Design Metal Temperature (MDMT) of -20°F at 150 PSI.

Testing and Quality Assurance: Prior to shipment, tanks undergo various documented tests, including dye penetrant examination, x-ray analysis, pressure testing, profilometer readings of surface finish, and fiber optic borescopic examination of contact surfaces.

Design Features: The tanks offer a range of customizable features, including:

Mechanical and electropolished surface finish to less than 10 microinches Ra
Stationary or portable design
Cone, sloped, or dished bottoms
Fixed or removable tops
Various port types, sizes, and locations
Heating and cooling jackets
Chloride-free insulation with stainless steel sheathing
Accessories such as lights, agitators, sightglasses, handholes, and sensors

Contact Information: Allegheny Bradford Corporation is located at 1522 South Avenue, Lewis Run, PA 16738. They can be contacted via phone at 800-542-0650 or fax at 814-362-2574. More information is available on their website at www.abccorporate.com.

Catalog excerpts

W MAWP 150 PSI AT 300 FMDMT -20 а F AT 150 PSIMAWP 150 PSI AT 300 FMDMT -20 а F AT 150 PSI >

Open the catalog to page 1

?Capacity and pressure rating? Mechanical and electropolished surface finish to less than 10 microinches Ra ?Stationary or portable design ?Cone, sloped or dished bottoms ?Fixed or removable tops ?Port types, sizes and locations ?Heating and cooling jackets ? Chloride-free insulation withstainless steel sheathing?Accessories such as lights,agitators, sightglasses, handholes and sensors >

Open the catalog to page 2

Our fabrication specialists use the finestmaterials available including type 304, 316 and 316L stainless steel. Beginning with the inspection of raw materials and throughout the manufacturing process, rigorous testing and documentation procedures assure compliance with the most stringent industry standards. Prior to shipment, your tanks undergo documented tests that may include dye penetrant examination, x-ray analysis, pressure testing, profilometer readings of surface finish and fiber optic borescopic examination of contact surfaces.All Allegheny Bradford custom tanks offer:?ASME Code Stamping...

Open the catalog to page 4
