Three things that belong together We will be happy to help! More proximity for new ideas Telephone number head office: +49 6205 3051-0 All good things come in threes. Within the Alfra product family, we see our switch cabinet and control construction, steel and metal construction and magnet and lifting technology divisions as „triplets“ with individual characteristics, connected by the Alfra DNA. That is why we have once again united the trio in a compact catalogue For you, this means the opportunity to browse through tool topics that do not directly concern your environment. Let us surprise...

CONTROL CABINET AND CONTROL ENGINEERING STEEL AND METAL CONSTRUCTION MAGNETICS AND LIFTING TECHNOLOGY TECHNICAL INFORMATION

Hole punchers MonoCut® / Sets Split hole punchers TriCut® / Sets Split hole punchers TriCut+® / Sets Split hole punchers FormCut® Split hole punchers FormCut+® Hole punchers Sanitary Hole punchers Sub-Min-D Hole punchers special forms / custom-made products Manual hydraulic punchers / sets Akku-Compact Flex® Hydraulic pumps Cutting devices for Profile rails Wiring duct cutting device CUTTING DEVICES FOR PROFILE RAILS AND WIRING DUCT Pages 33 - 36 ASSEMBLY TABLES BUSBAR MACHINING STATIONARY PUNCHING Busbar Machining Assembly tables AMT 150, AMTE 250 ALFRA PRESS Stationary punching machines

CONTENTS Application solutions for Steel and Metal Construction DRILLING Metal Core Drilling Machines Metal Core Drilling Accessories - Arbors Accessories – Coolant Accessories – Tapping Attachements Chip Remover Vacuum Plate CUTTING TOOLS Hole Saws HSS-Bi-Metal/Sets Multi-Step Drills Milford Sabre Saw Blades Hydraulic Punching Punches and punching dies Hydraulic Pumps Application solutions for Magnetics and lifting technology LIFTING Load-lifting -Flat steel Load-lifting - Round steel Positioning / Individualization Angle fixing INTERESTING FACTS ABOUT TML/TMC TECHNICAL INFORMATION Interesting...

APPLICATION SOLUTIONS FOR CONTROL CABINET AND CONTROL ENGINEERING MOBILE PUNCHING Showpiece pairs: Sheet metal punch and hand punch from Alfra Sharp cutting geometry meets hydraulic power – a delightful connection. Alfra sheet metal punchers convince as burr-free and low-noise alternative to saws. Using our hand punches, you can cut through housings faster and more efficiently than ever before. • Sheet metal punches for round, square and rectangular punching • Please do not hesitate to ask us about special products • Hydraulic hand punches for the various working situations • Depending on the...

ASSEMBLY TABLESFour-star workstation for panel builders The “customised workstation” is not just an empty phrase in our product range. The Alfra assembly tables AMT 150 and AMTE 250 are mobile and infinitely adjustable. This means they can be used exactly where they are needed and create space in the workshop at short notice if required. Assemble where and how you like - in your personal favourite working position. • Hold mounting plates with dimensions up to 1100 mm x 1900 mm • 4 swivel castors with total lock for safety and mobility • Adjustable tilt angle from 0 - 80 • Optional roller conveyor...

MonoCut® TriCut® TriCut+®Material thickness when using 1.5 mm custom-made products 0 for predrilling 0 6 mm draw bolt Hydraulic drive

BALL BEARING SCREW High-tensile bolts for the toughest operating conditions Protrusion of ball bearing outside protective ring ensures perfect force transmission to wrench or punching tool Ball bearings encapsulated in aluminium rings. Extremely long-life and perfectly protected against soiling

Hole puncher MonoCut® for sheet steel (S235) ,1 With UNF fine thread[2 With 4 crosshair markings for simple, central alignment “The max. material thickness for which a hole puncher can be used always depends on the screw and draw bolts used. ” Usable up to a material thickness of: • 3.0 mm sheet steel with 3/4" (19.0 mm) screw or draw bolt • 2.0 mm sheet steel with 3/8" (9.5 mm) screw or draw bolt Hole puncher MonoCut® - sets All sets are supplied in heavy-duty practical plastic cases.

Size Size Pipe Size Punches and dies draw bolt with matching draw bolt matching draw bolt ball bearing draw bolt matching draw bolt with ball bearing Hole puncher MonoCut® - for sheet steel (S235) 1 Above 0 68.0 mm we recommend the use of hydraulic equipment.

Split hole puncher TriCut® for sheet steel (S235) “The max. material thickness for which a hole puncher can be used always depends on the screw and draw bolts used. ” • 3.0 mm sheet steel with 3/4" (19.0 mm) screw or draw bolt • 2.0 mm sheet steel with 3/8" (9.5 mm) screw or draw bolt • 1.5 mm steel sheet with M6 (6.0 mm) screw or draw bolt Split hole puncher TriCut® - sets All sets are supplied in heavy-duty practical plastic cases.

Pipe Size Split hole puncher TriCut® - for sheet steel (S235)

Split hole puncher TriCut+* for sheet steel (S235) and stainless steel “The max. material thickness for which a hole puncher can be used always depends on the screw and draw bolts used. ” Usable up to a material thickness of: • 2.5 mm stainless steel with 3/4" (19.0 mm) screw or draw bolt • 2.0 mm stainless steel with 7/16" (11.1 mm) screw or draw bolt Split hole puncher TriCut+® - sets

Split hole puncher TriCut+® - for sheet steel (S235) and stainless steel (VA)

ALFRA HOLE PUNCHER® FORMCUT ® Hole puncher FormCut® 1 With sideways puncher part ejection 2 With UNF fine thread 3 With 4 crosshair markings for simple, central alignment 3 “The max. material thickness at which a square or rectangular hole puncher (or even special tool) can be used always depends on the draw bolt and the cross-section of the tool (length x width or special shape).” Hole puncher FormCut® – rectangular – for heavy plug connectors 4 centering mandrels are placed in the correct position at the die. When die and punch are pressed against each other, the drilling position gets marked...
