Vacuum Induction Degassing (VID)
Vacuum Induction Degassing (VID)
The document discusses the Vacuum Induction Degassing (VID) furnace, designed for the ferrous and non-ferrous metals industry, handling charge weights up to 30 tons. It is particularly beneficial for smaller steel shops and foundries to produce high-quality vacuum-treated steels economically.
Specifications
The VID system is vacuum-tight and tiltable, allowing for melting under vacuum, precise temperature adjustment, and processes like decarburization, desulphurization, and deoxidation. It supports alloying and pouring, with options for pouring at air (VID), under protective gas (VID-Pro), or with oxygen blowing (VID-Oxy).
Procedures
All secondary metallurgy treatment steps are integrated into one unit, including melting, refining, and casting. The VID-Pro variant allows pouring under inert gas, minimizing gas pick-up. The VID-Oxy variant is optimized for high-chromium steel production using low-cost materials and includes oxygen blowing for carbon removal.
System Configurations
The document outlines typical system configurations, including space requirements and technical data for different VID models (400, 1000, 2000, 3000). Key parameters include crucible size, cycle times, operating pressure, electrical layout, cooling water consumption, and recommended crane capacity.
Applications
VID systems are suitable for producing low and high carbon steels, tool and die steels, stainless steels, Fe-Ni alloys, superalloys, and non-ferrous alloys. They are effective in hydrogen and nitrogen removal, decarburization, and inclusion removal.
Contact Information
The document provides contact details for ALD Vacuum Technologies GmbH and its international offices in Great Britain, Russia, China, the Far East, and the USA/Canada.
Catalog excerpts
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:11.00pt "Impact", sans-serif; } .font1 { font:15.00pt "Impact", sans-serif; } Vacuum Induction Degassing VID 400 - VID 3000 Vacuum Treatment of Melts with Charge Weights up to 30 tons
Open the catalog to page 1
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Impact", sans-serif; } .font1 { font:6.00pt "Impact", sans-serif; } .font2 { font:7.00pt "Impact", sans-serif; } .font3 { font:9.00pt "Impact", sans-serif; } .font4 { font:11.00pt "Impact", sans-serif; } .font5 { font:12.00pt "Impact", sans-serif; } .font6 { font:13.00pt "Impact", sans-serif; } .font7 { font:17.00pt "Impact", sans-serif; } .font8 { font:22.00pt "Impact", sans-serif; } .font9 { font:9.00pt "Microsoft Sans Serif", sans-serif; } .font10 { font:60.00pt "Microsoft Sans Serif",...
Open the catalog to page 2
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:10.00pt "Impact", sans-serif; } .font1 { font:11.00pt "Impact", sans-serif; } .font2 { font:15.00pt "Impact", sans-serif; } 3 VID VID-Pro VID-Oxy Ml important secondory motallurgy treatment stops - melting under vacuum, refining such os decarburization, desulphurization, daoxidotion, removal of undesired gases like hydrogen and mlrogen, exact adjustment of chemicol □nalysis, cleaning, alloying, htating - are done in one single unit. The melt wiII bt cost at air The modified VID-Pro furnoce ollows...
Open the catalog to page 3
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Impact", sans-serif; } .font1 { font:9.00pt "Impact", sans-serif; } .font2 { font:10.00pt "Impact", sans-serif; } .font3 { font:13.00pt "Impact", sans-serif; } .font4 { font:11.00pt "Microsoft Sans Serif", sans-serif; } .font5 { font:33.00pt "Microsoft Sans Serif", sans-serif; } .font6 { font:18.00pt "Times New Roman", serif; } VIDSystemsandRfrences [3] VID-Pro VID-Pro 2000 - lit KM-Kabelmttall, Osnabri驯ck, Gernany Pouring of copper alloys under proteclive ineri wj ofmosihtre iito slol...
Open the catalog to page 4
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Impact", sans-serif; } .font1 { font:9.00pt "Impact", sans-serif; } 5 Production of spcial steels and low carbon steels
Open the catalog to page 5
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {}
Open the catalog to page 6
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:9.00pt "Impact", sans-serif; } .font1 { font:22.00pt "Impact", sans-serif; } 7 Typical system configuration
Open the catalog to page 7
VIDPNeu.QXD Englisch table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Impact", sans-serif; } .font1 { font:5.00pt "Impact", sans-serif; } .font2 { font:6.00pt "Impact", sans-serif; } .font3 { font:11.00pt "Impact", sans-serif; } .font4 { font:60.00pt "Microsoft Sans Serif", sans-serif; } Technical Data Characteristic Units VID VID VID VID 400 1000 2000 3000 Crucible size (metric tons) 1 - 3 4 - 8 9 - 16 17 - 30 Capacity (based on Ni) Typical cycle times Fe-Cr base alloy/ Fe-Ni base alloys/ special steels (h) 3 - 6 3 - 6 3 - 6 3 - 6 Typical operating pressure...
