Albin Pump ALH - High Pressure Peristaltic Pump
8Pages

ALBIN PUMP ALH HOSE PUMPS

ALBIN PUMP ALH HOSE PUMPS ALBIN PUMP ALH is a hose pump of the latest design. We have combined the best available materials with smart design solutions in order to maximise running time and minimise maintenance. Two shoes mounted at 180° on a rotating wheel compress successively a reinforced rubber hose that contains a fluid to be pumped. The compression of the hose by the rotating shoes creates continuous suction at the inlet of the pump and pushes the fluid to the outlet of the pump. The pump casing contains a lubricant that reduces friction and insures the best pump performance with a...

EXPERIENCED NEWTHINKER KEEP IT SIMPLE THE ALH PUMP is very easy to use and maintain and therefore addresses what we at ALBIN PUMP see as two of the key customer issues : the need to lower costs and to reduce downtime. This is done by using a pump without valves, pistons, stators or rotating elements in the fluid.The ALH series is designed to make hose changes quick and easy with no technical knowledge required. ALBIN ALH HOSE CONSTRUCTION We only work with high quality compounded rubbers, reinforced with 2 to 6 individual layers of braided polyamide and with an outer layer made to strict...

ALL DIMENSIONS AND TECHNICAL DATA IS SUBJECT TO CHANGE WITHOUT NOTICE

TECHNICALS CHARACTERISTICS FLOW TABLE (L/H) TYPE Intermittent use(L/h) ALBIN ALHS SERIE For customers who require a long shaft technology, ALBIN PUMP has also developed the ALHS series. These pumps are equipped with a removable bearing case for easy bearing maintenance and can be converted into a close coupling ALH type pump at any time. ALH PUMP FLOW CURVE - ALBIN ALH PUMP 0.55 Continuous service Intermittent service* 1 - Select the required flow. This gives you the required pumpspeed. 2 - Move upwards to the calculated discharge pressure. 3 - Move to the left for the installed motor...

FLOW CURVES ALBIN ALH Pump speed (Rpm) Flow (m3/h) * Intermittent use : Minimum of 1 hour stop after 2 hours use * Occasional use : Maximum 1 hour per day

FLOW CURVES ALBIN ALH * Intermittent use : Minimum of 1 hour stop after 2 hours use * Occasional use : Maximum 1 hour per day

For more information about our worldwide locations, approvals, certifications, and local representatives, please visit www.albinpump.com. ALBIN PUMP reserves the right to incorporate our latest design and material changes without notice or obligation. Design features, materials of construction and dimensional data, as described in this bulletin, are provided for your information only and should not be relied upon unless confirmed in writing. Certified drawings are available upon request. © 2008 ALBIN PUMP
