akYtec GmbH is a European manufacturer of industrial automation equipment, producing PLCs, HMIs, process indicators, I/O modules, and doudbased monitoring solutions. You can find our products in use across the world — from HVAC systems and water treatment plants to manufacturing lines, agricultural facilities, and many other applications. We put our customers at the center of everything we do. Our technical support team is available in English, German, Serbian, Polish, Turkish, Spanish, and many other languages, ensuring that communication is never a barrier. „From the very beginning, our approach...

DIGITAL PANEL METERS PLCs PROCESS CONTROLLERS SOFTWARE I/O MODULES LORAWAN DEVICES COMMUNICATION DEVICES SENSORS AND TRANSMITTERS OTHER EQUIPMENT We will be glad to assist you! Tel.: +49 (0) 511 16 59 672-0

DIGITAL PANEL METERS DIGITAL PANEL METERS Our universally applicable configurable digital displays are characterized by their compact design and unique form factor can be mounted in a 22.5 mm cutout for standard indicator lights or push buttons. These process displays require neither mounting screws nor special rectangular cutouts, which makes their installation on a control panel or control cabinet door quick, easy, and convenient. The wall-mount ITP11-W loop-powered digital display has a universal enclosure which can be snapped onto a DIN rail or attached to a tube. The akYtec process displays...

The ITP11 is a universal, microprocessor controlled display unit for monitoring industrial processes. The measured values are scalable. The ITP11 is designed to be connected to any transmitter with a 4-20 mA output. It requires no auxiliary power and is supplied directly from the current loop.This device has a compact enclosure that fits into a standard 022.5 mm mounting cutout, which provides quick and easy installation of many displays of this kind to be accommodated on a control panel or at the control cabinet door. • Visualization of any 4-20 mA signal received from a relevant output of a...

DIGITAL PANEL METERS The 4-20 mA process indicator ITP11 is particularly suitable for the fast and easy installation of visual display systems for various processes, such as water supply or thermal processing. The ITP11 can be used as an additional standalone display unit for on-site process visualization or as a part of a complex visual display system. Technical data: Power supply We will be glad to assist you! Tel.: +49 (0) 511 16 59 672-0

PROCESS INDICATOR 4-20MA (WALL-MOUNT) ITP11-R-W / ITP11-G-W The ITP11-W is a universal applicable display unit for monitoring of industrial processes. It connects to any 4-20 mA output to visualise the present signal. This process display requires no auxiliary power and is supplied directly from the current loop. The ITP11-W is delivered in a dust-tight and water-resistant IP65-rated enclosure suitable for DIN-rail or wall mounting as well as a firm fixation on a tube (up to 0200mm). • Visualization of any 4-20 mA signal received from a relevant output of a sensor, PLC, I/O module, etc. • Display...

Technical data: Supply current Wiring diagrams: Two-side connection: Connection from the right: Mounting types: akytec We will be glad to assist you! Tel.: +49 (0) 511 16 59 672-0

UNIVERSAL PROCESS INDICATOR 0-10 V/4-20 MA The ITP14 is a universally-applicable process display for monitoring and control of industrial processes. This display features a configurable current/voltage input and an NPN transistor output. The NPN transistor output makes it possible to implement on-off control of a low voltage relay up to 42 V DC / 200 mA. This device has a compact enclosure that fits into a standard 022.5 mm mounting cutout, which provides quick and easy installation of many displays of this kind to be accommodated on a control panel or at the control cabinet door. • Display of...

DIGITAL PANEL METERS The universal display ITP14 is particularly suitable for the fast and easy installation of visual display systems for various processes, such as water supply, thermal processing, and many others. The ITP14 can be used as an additional standalone display unit for on-site process visualization or as a part of a complex visual display system. Technical data: Electrical connection: akytec We will be glad to assist you! Tel.: +49 (0) 511 16 59 672-0

ITP15 The ITP15 Bar Graph Display is a compact process indicator that is intended to visualize an analog input signal in the range from 0 to 100% with 10 bars 10% each. The input signal can be either a linear voltage signal of 0(2)-10 V or a current signal of 0(4)-20 mA. Due to cylindrical form of the mounting part of the enclosure, the device can be positioned either vertically or horizontally without changing the mounting cutout. The ITP15 fits into a standard cutout of 022.5 mm. The cutouts of the same diameter are commonly used for mounting standard signal lamps or push buttons at control...

Technical data: Power supply The bars can change their color if the process value crosses the setpoints. Electrical connection: Current sensor wiring Voltage sensor wiring akytec We will be glad to assist you! Tel.: +49 (0) 511 16 59 672-0

ITP15-M The ITP15-M Bar Graph Display is a compact panel-mount process indicator designed to visualize an analog input signal ranging from 0 to 100% with 10 bars, each representing 10%. It features a three-color display that shows parameters in green, yellow, and red. You can customize the thresholds for color changes to suit their specific needs. The ITP15-M's compact and standardized design fits into a standard 22.5 mm borehole for signal lamps, allowing for quick and simple installation. • Three-color 10 segments indicator (green\red\yellow) • Configurable analog input (0-5 mA, 0(4)-20 mA,...

DIGITAL PANEL METERS Technical data: Power supply Mounting cutout: Wiring diagram: Operation modes: akytec We will be glad to assist you! Tel.: +49 (0) 511 16 59 672-0
