Metalworking Mist Collection Systems
8Pages

Performance l Productivity l Payback

Market Driven Product Solutions Airflow Systems, Inc.® manufactures a full line of mist collection and filtration systems for all types of metalworking applications, including wet grinding, EDM, and CNC turning and milling. Extensive field experience and technological expertise are the basis for product designs that help to satisfy worker, facility, regulatory, and budgetary demands in each type of metalworking application. Oil Mist Collection: Pushing the Limits In 1999, the Metalworking Fluids Standards Advisory Committee (MWFSAC) recommended to OSHA that the total exposure level limit of...

Airflow Mist-Plus : Oil Mist Contaminant Management ™ Leaving Dust Filters in the Dust Most pleated and pocket filter-type mist collectors are design adaptations of dry dust collection systems and are inadequate for many types of oil mist collection — particularly respirable droplets of 3.0 microns and smaller. Dust filter-type designs typically load quickly with oil mist and provide little or no drainage. As a result, filters must be changed often to maintain collection efficiency and acceptable air flow levels. The Mist-Plus™ Contaminant Management System, designed specifically for oil...

Mist-Pak Series Models MP4 & MP14 ™ The Model MP4 is designed for single-unit metalworking applications. It produces from 400 to 600 CFM with 95% filtration efficiency. The Model MP4 features a bottom inlet for simple, machine-top mounting or above unit hanging. Its small, 1.8 square foot cabinet footprint requires minimal floor space and eases installation. Air Flow Efficiency Inlet (CFM) bottom only Weight Sound Level Blower (lbs.) (dBA) Package(s) 105 Filter Modules 0.75 HP single or three phase 1” aluminum mesh pre-filter; (1) Mist-Plus™ primary filter (Circular design) Weight Sound...

Mist-Pak Series Models MP30 & MP60 ™ The Model MP30 is designed for use in medium- to heavy-duty metalworking applications. It produces from 2400 to 3000 CFM with 95% filtration efficiency. The MP30 features multiple inlet location options to easily facilitate collection from multiple machine tools. Its small, 4 square foot cabinet footprint requires minimal floor space. Units can be hung or floor mounted. Air Flow Efficiency Inlet (CFM) 14” sides & back only; 12” front Weight Sound Level Blower (lbs.) (dBA) Package(s) 350 Filter Modules 5 HP, 2” aluminum mesh 3 HP (optional) pre-filters:...

Mist-Pak Series Model MP120 ™ The Model MP120 is designed for use in extremely heavy-duty, multiple machine tool metalworking applications. It produces 12,000 CFM, with 95% filtration efficiency. The MP120 features a sloped drain pan for faster reclamation of captured oil mist, and a 24 inch stand for floor mount installation. Model MP30 Shown Air Flow Efficiency Inlet (CFM) 12,000 Weight Sound Level Blower (lbs.) (dBA) Package(s) Filter Modules (4) 2” aluminum mesh pre-filters; (16) Mist-Plus™ primary filters (V-shape design) *Efficiency based on UAW-approved UNC oil mist test method....

Models Pro 1 and Pro 2 provide ultra-high efficiency filtration of oil, coolant, and other mists generated during metalworking applications. Pro 1 and Pro 2 models deliver 99.97% efficiency at 3.0 micron particle size. Cabinet seams are welded, not bolted; and filters are secured with the Ultra-Seal® filter mounting system to eliminate contaminant bypass and escape. Air Flow Efficiency Inlet (CFM) Weight Sound Level Blower (lbs.) (dBA) Package(s) Filter Modules 99.97% with HEPA after-filter MistPlus® II ultra-high efficiency 99.97% with HEPA after-filter MistPlus® II ultra-high efficiency...

E-Z Arm ® Extractor Arms Positionable, high-efficiency units provide source-point collection in a variety of applications. Model choices include units for close-in work and multiple-arm collection, as well as stainless steel and food grade units. Arms are available in a range of lengths and air flow capacities. Portable Collectors Easily wheeled directly to a pollutant source, these complete, self-contained, low profile units feature an E-Z Arm® High Flow Extractor Arm, blower, and filter cartridge. A low profile cabinet allows for safe maneuverability and arm positioning. Downdraft Benches...
