EPH-EGT Compact Extraction Arms Catalogue

Product catalog summary

Overview: The document provides technical specifications and installation guidelines for the EGT and EPH series of compact extraction arms, designed for the extraction of fumes, dust, and industrial pollutants. These arms are suitable for environments with predefined extraction areas and low ceilings.

EPH Series - Extraction Half-Arms:

Specifications: Features a self-supporting double-pantograph aluminum structure, a 360° swivel base, and a galvanized and painted extraction hood for hot fumes. Operating temperature ranges from -20°C to 90°C.
Advantages: No height encumbrance, components not immersed in suction flow, and a wide range of accessories and special versions available.
Applications: Ideal for low ceiling premises and predefined suction areas requiring periodic repositioning of the hood.
Installation Options: Wall bracket, ceiling extension, floor stand, sliding trolley, and extraction jib extension.

EGT Series - Telescopic Extraction Arms:

Specifications: Telescopic tube extends to 300 or 700 mm, available in ATEX version and AISI 316 stainless steel. Operating temperature ranges from -20°C to 90°C.
Advantages: No height encumbrance, wide range of accessories, and suitable for all types of installations.
Applications: Suitable for rooms with low ceilings or where minimal encumbrance is needed.
Installation Options: Wall bracket, ceiling extension, floor stand, sliding trolley, and extraction jib extension.

Technical Data:

EPH Series: Available in various lengths and diameters, with specific codes for laboratory and industry models.
EGT Series: Available in different lengths and diameters, with specific codes for hanging versions.

Contact Information: AIRBRAVO S.r.l., Viale Enrico Ortolani, 246, 00125 Roma, Italy. Tel: +39 06 5219748 / 5210067, Email: [email protected], Website: www.airbravo.com

Catalog excerpts

EPH-EGT Compact Extraction Arms Catalogue-1

PURIFIED AIR AT WORK SINCE 1976 COMPACT EXTRACTION ARMS Minimum overall dimensions for extraction of fumes, dust and industrial pollutants from predefined sources
