AcraDyne DC Controlled Tools Catalog
20Pages

{{requestButtons}}

Catalog excerpts

AcraDyne DC Controlled Tools Catalog - 2

About AIMCO. . . . . . . . . . . . . . . . . . . . . 3AcraDyne DC Controlled Tools. . . . . . . . . 4 Benefits of PERQ. . . . . . . . . . . . . . . . . . 5 Specialized Applications. . . . . . . . . . . . . 6 System Components. . . . . . . . . . . . . . . . 7 AcraDyne iEC Controller. . . . . . . . . . . . . 8 ToolWare > 2007 Software. . . . . . . . . . . 10AcraDyne Angle Nutrunners. . . . . . . . . . 14 AcraDyne Inline Nutrunners. . . . . . . . . . 15 AcraDyne Pistol Grip Nutrunners. . . . . . 16 AcraDyne Tubenut Nutrunners. . . . . . . . 17 Accessories. . . . . . . . . . . . . . . . . . . ....

Open the catalog to page 2
AcraDyne DC Controlled Tools Catalog - 3

Founded in 1970, AIMCO has built an internationalreputation for providing the highest quality products, exceptional service and support to the manufacturing industry. As the industry leader, AIMCO has created long term partnerships that continue to grow to this day. AIMCO understands the needs of the customer and specializes in going above and beyond to provide the service and support needed for every job. Expect the best when you partner with AIMCO. > ■ Represents Manufacturers From Over 13 Countries > ■ Fast Response Time > ■ Constant Flow of New ProductsToday, innovation, flexibility,...

Open the catalog to page 3
AcraDyne DC Controlled Tools Catalog - 4

Invest in AcraDyne DC tools they will pay you backin dividends! ע֠ Reduce assembly costs ■ Detect errors earlier ■ Increase production ■ Network entire systems > ■ Tightening Efficiency Torque is achieved by aspecific strategy within a parameter set reducing stress and wear on mechanical components ע֠ Run multiple torque or angle targets with one tool ■ Complete Assembly No more missed screws ע֠ Automated Eliminates operator fatigue and missedfasteners ע֠ Repeatability Consistent tightening strategies oneither hard or soft joints ע֠ Speed control ■ Angle control protects against damaged...

Open the catalog to page 4
AcraDyne DC Controlled Tools Catalog - 5

PERQ > SM , combined with AIMCOגs integrated productgroups and industry experience, enables manufacturers and assemblers worldwide to compete in todays competitive global marketAIMCO and our suppliers are committed to improvingeach element of the PERQ > SM formula: P roductivity, E rgonomics, R eliability and product Q uality.The goal of a competitive manufacturer and assembleris to optimize and balance the four elements of PERQ > SM to increase revenues and reduce costs. > Ң֠ Fastest DC motors in the industry ■ On-board Tool ID for fast set-up ■ Flexible I/O functions allow for extensive...

Open the catalog to page 5
AcraDyne DC Controlled Tools Catalog - 6

AIMCO is able to integrate the AcraDyne tool spindle into a customized Multiple Nutrunning System that will address your needs. From simple systems vertically suspended above the part to assembly stations that integrate with your line, AIMCO can handle your project. Let us know your requirements and we will propose a solution tailored to your needs. > ■ Wheel lug nut assembly ■ Four spindle 105 Nm ■ Rotating spindle trunnion ■ Replaced competitive system ■ Built-in PC for data storage > ■ Gasoline generator assembly ■ Six spindle 30 Nm ■ Replaced hand assembly withrotation pattern to...

Open the catalog to page 6
AcraDyne DC Controlled Tools Catalog - 7

■ NEMA 12 rated enclosure ■ Easy access to internal components ■ Smaller design for easier mounting ■ 110V or 220V flexibility > ■ Standard GFCI (Ground FaultCircuit Interrupter) > 1 Tool Cable Connection Process Indicator Lights > 2 Accept, Torque, Angle, Cycle For simple interface with external devices. Software is available to configure the controller to receive and process standard bar code input (iEC3 and iEC3K only). > 3 Large, Easy-to-Read Torque/Angle Display Optional Keypad Display Module (KDM) I/O 8 In and 8 Out Wall Mount Brackets Safety Interlock Bar Code Input >

Open the catalog to page 7
AcraDyne DC Controlled Tools Catalog - 8

■ Data Storage Standard units store 2,040rundowns. 10,000,000 rundowns or more are possible with advanced network capable units ע֠ ToolWare > ΗCustom-designed operating systemmeans no licensing fees ■ Backwards Compatible Works with any AcraDyneDC tool ע֠ Parameter Set Select and Indication Changeoperations and clear indication of your current operations with one button ע֠ External Port Software Updates Plug-in capabilityfor software updates ע֠ Tool Calibration Routines Stores the calibrationdirectly in the toolגs memory for easy plug and play into any AcraDyne controller ■ Rundown Storage...

Open the catalog to page 8
AcraDyne DC Controlled Tools Catalog - 9

■ Controlled tightening improves quality ■ Torque Control (TC) Provides target torque withhigh and low limits with simple pass or fail criteria for tightening threaded fasteners ע֠ Process controls ensure no missed screws, strippedscrews, rehits or damaged threads ■ Eliminates human error ■ Torque Control with Angle Monitoring (TC/AM) For tightening threaded fasteners, allows you to monitor angle and rotation to detect any changes in the joint rate which would indicate process problems ע֠ Consistent torque control ■ Accurate tightening means better end-product quality ■ Torque Monitoring...

Open the catalog to page 9
AcraDyne DC Controlled Tools Catalog - 10

ToolWare 2007 is AcraDynessoftware package designed specifically for AcraDyne tools and controllers. Provided at no cost to all users, this comprehensive, user-friendly program allows programming, analysis and diagnostics via Ethernet, USB or parallel connection to any Windows Ү computer workstation. The software automatically detects the controller or can be used offline. Easy Parameter Set Set-Up Adding and editing parameter sets is simple with ToolWare 2007s Intuitive Parameter Set-up Function. 10 AIMCO/ 1-800-852-1368 >

Open the catalog to page 10
AcraDyne DC Controlled Tools Catalog - 11

Ι With CurveWare, fast access to torque and angle curves allows the tool andcontroller to be programmed for optimal performance on any application. > Vital statistics and rundown plots can be quickly viewed to assure the assembly process is being performedproperly. >

Open the catalog to page 11
AcraDyne DC Controlled Tools Catalog - 12

Advanced Application Features User designated log-in permission allows access to a wide range of programming andconfiguration options, from Soft Start Delay time through Rundown-Backoff-Rundown strategies. Batch Processing Whether simple or complex, batch jobs can be quickly set up using a variety of programming options. 12 AIMCO/ 1-800-852-1368 >

Open the catalog to page 12
AcraDyne DC Controlled Tools Catalog - 13

I/O Monitor For testing and visualization ofprocesses, the I/O Monitor feature allows fast and informative observation of the controllerΒs Fixed Logic I/O. Calibration and Maintenance Scheduling Programmable intervals and alerts provide immediate notice that the tool and/or controller are in need of scheduled preventative maintenanceor calibration. AIMCO/ 1-800-852-1368 > 13 size="-2">

Open the catalog to page 13
