Software 11/2025 • We reserve the right to make technical changes. AMR WinControl the software for all ALMEMO® measuring instruments Software Description: • Software for acquiring, displaying and processing measured data of the ALMEMO® device series (V5, V6, V7) • Convenient programming and operation of the devices. • Graphical display, mathematical processing and printing (measurement report) of current and saved data. • Appropriate for long term measurements (GMP) or for control and monitoring tasks. Can be easily adapted to every project. • Fast familiarization and safe operation thanks to Windows interface and the context-sensitive help. • Further information and the current demo version are available under www.akrobit.de. Software Versions: Light: For 20 measuring points and one instrument Standard: For any number of measuring points and instruments Pro: For any number of measuring points and instruments, all options included (except Data server, Web server and additional modules) Server: For any number of measuring points and devices, all options included (except add-on modules), with an integrated data server (simultaneous access by several RMT WinControl clients). Update: of the latest software version for older versions of the latest software version for newer versions Options: Network capability (for addressing several ALMEMO® devices) Automatic generation of measured data files (daily files / weekly files) Alarm function (alarm record, output to ALMEMO® relays, starting other applications) Data server Web server Extended evaluation functions Fast scanning of measured values for V7 devices (up to 1000 mops online) PIMEX Player: combined measured value display and video display Additional modules: Thermal comfort and air-conditioning calculations (as per DIN 1946, EN ISO 7730) Password protection Test bench manager (prerequisite: WC3 / WC4 or WC1 / WC2 + WCO2) Thermal transmittance (U) wizard Thermal quantity wizard OPC export Additional protocol (selectable, requires WC3 / WC4) The memory is read out automatically Automated printing (line diagrams, tables) (needed: WC3/WC4 or WC1/WC2 + WCO2) ODBC-Support (export to SQL-databases) Assistant for calibrating measuring sensors (needed: WC3/WC4) Assistant for calibrating climate cabinets (needed: WC3/WC4) PIMEX Recorder: combined measured value recording and video recording (needed: WC3/WC4) Assistant for refrigerant Assistant for A0/F0 value Assistant for process sequence and setpoint generator (needed: WC3/WC4) Complete packages: Long-term / continuous monitoring CAN Trace: combined measured data recording and CAN data recording as well as evaluation functions Hardware copy protection: USB dongle akrobit® license server 132

11/2025 • We reserve the right to make technical changes. Function overview

Data reduction Averaging function (ONLINE and OFFLINE) Smoothing (over time / over number of values, ONLINE and OFFLINE) Data logger functions Programming the data logger (including averaging functions) Read out from device memory (all / selective measured values) Display of memory occupancy status Alarm functions Alarm value display in measuring points list and in all measured value displays Alarm report with confirmation and comments text Events list (audit trail) Start a program in the event of a particular fault Send e-mail / SMS in the event of an alarm Switch ALMEMO® output relays (specific...

11/2025 • We reserve the right to make technical changes. Automation of test stations • Management of up to 150 independent test stations (basic configuration: 10). • Storage of assigned measurement data in separate files for each test station. • Input of test parameters (DUT, tester, etc.) and data for controlling the test when starting a test station. • Control of the test station and the test item via calculation channels and the setpoint generator. • Export and archiving of test results. • Output of test reports as PDF or to a printer. • E-mail dispatch after the test. • Optional: Control...
