Ceramic Division - Sanitaryware

Product catalog summary

Company Overview: ADI (Applicazione del Diamante Industriale) is a leading company in the production of diamond tools, founded in 1980. It employs over 170 people and specializes in tools for mechanics, glass, optics, stone, and ceramics. The company is known for its flexibility, deep product knowledge, and innovative design capabilities. ADI collaborates with machine manufacturers to optimize tool performance and has a network of experienced technicians to assist customers.

Product Specifications:

Grinding Wheels: Various dimensions are available for different machines, including COMEP and WENZLER, with sizes ranging from Ø 80x7x7 to Ø 280x10x15.
Cutting Discs: Segmented and continuous rim cutting discs are available in diameters from 80 to 625 mm.
Cup Grinding Wheels: Designed for hand-held machines with dimensions Ø 100x20x4.
Countersinks and Router Bits: Segmented countersinks and brase-welded router bits are available in various sizes.
Core Drills: Continuous rim with slots core drills available in diameters from 8 to 100 mm.
Adaptor for Core Drills: Spindle shank dimensions are 12 - 1/2 “ Gas.

Contact Information: ADI S.p.a. is located in Thiene, Italy, with a branch in Sassuolo. Contact details include phone numbers, fax, and email, with additional information available on their website.

Catalog excerpts

D I A M O N D T O O L S Ceramic Division Utensili per Sanitari_Tools for Sanitaryware D I A M O N D T O O L S

Open the catalog to page 1

ADI (Applicazione del Diamante Industriale) è un’azienda leader nella produzione di utensili diamantati. Fondata nel 1980 conta attualmente più di 170 dipendenti ed è leader nella produzione di utensili diamantati per l’industria della meccanica, vetro, ottica pietra e ceramica. Le caratteristiche qualificanti dell’Azienda si possono così riassumere: elevata flessibilità, profonda conoscenza del prodotto diamantato, elevata capacità progettuale ed innovativa. ADI collabora con i costruttori di macchine nei diversi settorii per ottimizzare le performance operative degli utensili. La rete commerciale...

Open the catalog to page 2

Mola per Rettifica COMEP Wheel for COMEP Grinding Machine Dimension: Dimensions: 250x5x15 F=50 - FINE

Open the catalog to page 3

Mola per Rettifica WENZLER Wheel for WENZLER Grinding Machine Dimension: Dimensions: Ø 280x10x15 F=170

Open the catalog to page 4

Mola per Rettifica WENZLER Wheel for WENZLER Grinding Machine Dimension: Dimensions: Ø 200x5x15 F=160 Mola per Rettifica WENZLER Wheel for WENZLER Grinding Machine Dimension: Dimensions: Ø 206x25x5 F=160

Open the catalog to page 5

Mole per Rettifica SETEC - METALTECNICA - CINGOLANI - GIERRE Wheels for SETEC - METALTECNICA - CINGOLANI - GIERRE Grinding Msachines Dimension: Dimensions: Ø 80x7x7 F=22 Ø 100x7x7 F=22

Open the catalog to page 6

Mole per Rettifica SETEC - METALTECNICA - CINGOLANI - GIERRE Wheels for SETEC - METALTECNICA - CINGOLANI - GIERRE Grinding Machines Dimension: Dimensions: Ø 65x7x5 Ø 80x7x5 Ø 100x7x5 Ø 110x7x5

Open the catalog to page 7

Mole per Rettifica SETEC - METALTECNICA - CINGOLANI - GIERRE Wheels for SETEC - METALTECNICA - CINGOLANI - GIERRE Grinding Machines Dimension: Dimensions: Ø 80x10x5 Ø 100x10x5

Open the catalog to page 8

Disco da Taglio a Settori Segmented Cutting Disc Diametri disponibili Available diameters: 200 - 250 - 300 - 350 - 400 - 450 - 500 - 550 - 600 - 625 Disco da Taglio a Fascia Continua Continuous Rim Cutting Disc Diametri disponibili Available diameters: 80 - 85 - 100 - 110 - 115 - 125 - 150 - 160 - 180 - 200 - 230 - 250 - 300 - 350 - 400 - 450

Open the catalog to page 9

Platorelli Flex Cup Grinding Wheels for Hand-held Machines Dimension: Dimensions: Ø 100x20x4 F=22.2 Svasatore Set Segmented Countersink Dimension: Dimensions: Ø 80 / 40 A=1/2 “ GAS Frese a Candela Saldo Brasate Brase-Welded Router Bits Dimensioni: Dimensions: Ø15x25 G=6x40

Open the catalog to page 10

Foretti a Fascia Continua con Intagli Continuous Rim with Slots Core Drills Diametri disponibili: Available diameters: 18 - 20 - 22 - 24 - 25 - 27 - 28 - 30 - 32 - 35 - 40 - 45 - 48 - 50 - 55 - 60 - 65 - 75 - 80 - 100 Foretti a Fascia Continua con Intagli Continuous Rim with Slots Core Drills Diametri disponibili: Available diameters: 8 - 10 - 12 - 13 - 14 - 15 - 16 Attacco Portaforetti Adaptor for Core Drills Dimensioni: Mandrino St. 12 - 1/2 “ Gas Dimensions: Spindle Shank 12 - 1/2 “ Gas

Open the catalog to page 11

ADI S.p.a. 36016 Thiene (Vi), Italy Via dell’Economia, 12/16 T +39 0445 360244 F +39 0445 366862 [email protected] Sede di Sassuolo Sassuolo Branch 41049 Sassuolo (MO) Italy Via Londra, 20 Tel. +39 0536 810628 / 811310 Fax +39 0536 810629 www.aditools.com www.imagination.it

Open the catalog to page 12
