Telescopic ball bearing slides available from stock Glissières télescopiques à billes disponibles sur stock Teleskop-Kugellagerlaufschienen ab Lager erhältlich Industrial/Electro Mechanical Product Catalogue 2009

Product index Index des produits / Produkt-Index Light duty slides, load rating up to 50kg Glissières de petite capacité, charge jusqu'à 50 kg Schienen für niedrige Belastungen, Lastwert bis 50kg Two-way travel / double course / Auszug in beide Richtungen 2002 35kg . . . . . . . . . . . . . . . . . . . . . . . .p32 2026 50kg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .p33 3630 45kg . . . . . . . . . . . . . . . . . . . . . . . .p34 75% extension / course 75% / Teilauszug 2421 16kg . . . . . . . . . . . . . . . . . . . . . . . .p35 DS2728 20kg . . . . . . . . . . . . . . . . ....

3832DO 50kg . . . . . . . . . . . . . . . . . . . . . . . .p55 DH3832 50kg . . . . . . . . . . . . . . . . . . . . . . . .P57 633xx Clip-on brackets / Équerres clipsables / Aufsteckwinkel . . . . . . . . . . . . . . .p59 100%+ extension / course 100%+ / Überauszug 7400-50SC 45kg . . . . . . . . . . . . . . . . . . . . . . . .p60 DA5321 50 kg . . . . . . . . . . . . . . . . . . . . . . .p61 Medium duty slides, load rating 51 - 99kg Glissières de moyenne capacité, charge 51 - 99 kg Schienen für mittlere Belastungen, Lastwert 51 - 99kg Linear / Guidage linéaire / Linearbewegung 0115RS 60kg . ....

75% extension / course 75% / Teilauszug 0204 65kg . . . . . . . . . . . . . . . . . . . . . . . .p65 DS2028 65kg . . . . . . . . . . . . . . . . . . . . . . . .P66 100% extension / course 100% / Vollauszug DS0330 65kg . . . . . . . . . . . . . . . . . . . . . . . .p67 100%+ extension / course 100%+ / Überauszug 2907 55kg . . . . . . . . . . . . . . . . . . . . . . . .p68 2907WB 55kg . . . . . . . . . . . . . . . . . . . . . . . .p69 5517-50 55kg . . . . . . . . . . . . . . . . . . . . . . . .p71 3301 68kg . . . . . . . . . . . . . . . . . . . . . . . .p72 3307 68kg . . . . . . . . . . . . ....

5321SC 120kg . . . . . . . . . . . . . . . . . . . . . . .p92 5321 180kg . . . . . . . . . . . . . . . . . . . . . . .p93 DS5321 180kg . . . . . . . . . . . . . . . . . . . . . . .p94 0522 180kg . . . . . . . . . . . . . . . . . . . . . . .p95 Corrosion resistant slides Glissières résistant à la corrosion Korrosionsbeständige Schienen DS2728 20kg . . . . . . . . . . . . . . . . . . . . . . . .p36 DH3832 50kg . . . . . . . . . . . . . . . . . . . . . . . .p57 100% extension / course 100% / Vollauszug 3607 120kg . . . . . . . . . . . . . . . . . . . . . . . .p80 9301 227kg . . . . . . . . . ....

The most comprehensive range of off-the-shelf telescopic slides in the world Accuride has been at the forefront in the design and manufacture of telescopic slides and access and movement systems since 1962. Our products are built into many industrial applications such as commercial and industrial machinery, electronic units and test equipment, and into a variety of transport applications such as emergency vehicles and trucks as well as aircraft, trains, ships and boats. They ensure the smooth movement of sliding components, contributing significantly to optimum space utilization, efficient...

Slide selection There are five stages in the selection of the most appropriate slide for your application. 1. Load rating • Load ratings quoted are the maximum for a pair of 450mm long vertically (side) mounted slides installed 450mm apart. • In general, wider drawers require a slide with a higher load rating and a cross section designed to withstand lateral stress. Our technical department will be pleased to advise you. • Load ratings will change according to the length of the slide. See individual datasheets for details. • Ratings are based on frequent use up to 10,000 cycles. See...

2. Extension or travel • 75% extension – drawer opens approximately 75% of the total length of the slide • 100% extension – drawer opens the same amount as the slide length • 100%+ extension – over-travel is achieved. The drawer opens in excess of the slide length. • Most full (100%) extension slides have nominal overtravel. Please see individual pages for details. 3. Slide length • Slide length is measured as the longest dimension of a fully closed slide. As a rule, always use the maximum length allowable in the application. Good OK SL = Slide Length TR = Travel Not Recommended . . 11/08...

4. Side space • The amount of space necessary to accommodate the thickness of the slide assembly. • For optimum performance allow between +0.2mm and +0.5mm over the nominal slide thickness, e.g. for a 12.7mm slide, the side space allowance should be between 12.9 and 13.2mm. • Precision slides cannot absorb large gap deviations between the cabinet and the drawer. The cabinet and drawer must be square and parallel to each other for optimal working of the pair of slides. 5. Determine any special features required • Disconnect allows simple connect/disconnect from the slide assembly Lever -...

• Material/finish Members - cold rolled mild steel (FeP01Am) - cold rolled stainless steel (1.4301 austenitic steel) - aluminium (AlMg3) Ball retainers - cold rolled zinc plated (FeP01Am) - stainless steel (1.4301 austenitic steel) - plastic (Nylon 6-6) Ball bearings - carbon chrome steel (grade 200) - stainless steel (1.4034 ferritic steel) - plastic (Delrin) Lubricant - Hi-Lo temperature grease, minimum operating range -20° to +110° • Slide ordering prefixes are: - DZ- electro zinc plate and blue passivate - DB- electro zinc plate and black passivate - DW- white - DH- corrosion resistant...

Quick reference guide 04/09 Accuride reserve the right to alter specifications without notice Accuride se réserve le droit de modifier les spécifications sans préavis Technische Änderungen vorbehalten 12
