Overview: This document is a catalog from Accuride International, detailing their precision ball bearing slide products for wood furniture and cabinetry, as of Fall 2007. It includes product specifications, selection criteria, and technical information to assist in choosing the appropriate slide for various applications.

Company Background: Accuride International began in 1962 as a tool and die shop in California, expanding to become the largest company dedicated to ball bearing slides. They maintain strict quality standards and have facilities worldwide, with a significant focus on in-house manufacturing processes.

Design and Load Factors: The catalog provides guidance on selecting slides based on length, extension, drawer width, and types of movement. It emphasizes the importance of testing slides in their intended application due to factors like shock, vibration, and environmental conditions.

Technical Support: Accuride offers extensive technical support and resources online, including FAQs and technical sheets, to assist with product selection and installation.

Compliance and Standards: Accuride products meet ANSI standards and are RoHS compliant. The company was the first U.S. slide manufacturer to receive ISO 9000 certification, ensuring high-quality management systems.

Product Specifications: The document provides detailed specifications and features of various drawer slide models offered by Accuride International. The slides are categorized based on their load ratings, extension capabilities, and specific applications, ranging from light to heavy-duty uses.

Conclusion: Accuride International provides a comprehensive range of drawer slides catering to different load requirements and applications, with various optional features and accessories to meet specific installation needs.

Media Access Centers (M.A.C.): These units provide easy access to media components and are suitable for security and electronic control centers, sound systems, and lecterns. The CBMaC-50 supports up to 150 lbs and accommodates shelving units up to 36" tall, while the CBMaC-100 supports up to 300 lbs and accommodates units up to 55" tall. Both models feature 90° rotation for full access, detent-in and detent-out for secure placement, and cable management systems.

TV Swivels: Accuride TV Swivels are designed for various television sizes, including flat panels up to 65" wide. The CB3620-258TV supports up to 225 lbs and offers a 360° swivel, while the CB9320-258TV supports up to 325 lbs and includes optional bracket kits for flat panel TV mounts.

Quick Lift: The CBLift-050 is a remote-controlled lift for flat-panel televisions up to 50" diagonal and 33.5" tall. It features reinforced steel rails, an auto-reverse mechanism, and standard and key fob-sized remote controls.

Flipper Door Slides: These slides are designed for various door sizes and applications, including entertainment cabinets and office storage. The Pro Pocket model 1321 supports doors up to 42" tall and 24" wide, while the Anti-Rak Cable System models 1332/1432 support taller, heavier doors up to 78" tall and 26" wide.

Specialty Slides: Accuride offers a range of specialty slides for different applications, including pencil drawer slides, keyboard systems, and pull-out storage slides. These slides feature steel ball bearings, various load ratings, and options for friction or lever disconnects.

Specifications and Features:
1. 3/4 Extension Slides: Designed for drawers up to 12 inches wide, these slides offer a 3/4 extension with a side space of 0.38 inches. They are non-disconnect, made with steel ball bearings, and available in lengths from 12 to 28 inches with a clear zinc or black finish.
2. Full Extension Slides: Suitable for drawers up to 16 inches wide, these slides provide full extension plus an additional 0.88 inches. They feature a side space of 0.76 inches, non-disconnect, and are available in the same lengths and finishes as the 3/4 extension slides.
3. Special Features: Include shelf/bottom mount tabs, internal detents for secure positioning, and access from both sides of installation.

Load Ratings and Applications:
1. 50 lb. Load Rating: Ideal for pass-through shelves, kitchen islands, and medical carts.
2. 100 lb. Load Rating: Designed for entertainment center shelves, appliance drawers, and pan shelves.
3. 110 lb. Load Rating: Known as the butcher block slide, suitable for cutting boards, printer, and work surface shelves.
4. 130 lb. Load Rating: Used for shelf or platform mounted pull-outs in pantries or entertainment centers.
5. 175 lb. Load Rating: StowAway slides keep waste containers and utility bins neatly out of sight.

Slide Protectors: These protectors prevent over-spray damage during finishing processes and are reusable. They are compatible with the 3832 family, 400 series, and 7432/7434 slides.

Warranty Information: Accuride offers a Limited Lifetime Warranty against defects in material and workmanship for original purchasers. The warranty covers replacement but not removal, installation, or incidental charges. It excludes products sold and used outside the US and Canada and does not apply to certain products like the Easy-Down® Flipper Door Slide®.

Contact Information: Accuride International has headquarters in North America, Europe, and Asia, with contact details provided for each region.
