1000VA Rugged, Industrial Quality DC-AC Inverter with Sine Wave Output Voltage CSI 1K-3U2, CSI 1K-3U3 Series • • • • • Sinusoidal output voltage Rugged, field-proven design Filtered input Cooling by internal fans Full electronic protection 3U3 Chassis for low input only: up to 36V This rugged, industrial quality DC-AC inverter utilizes field-proven, microprocessor controlled high frequency PWM technology to generate the required output power with pure sine wave output voltage. It is a mature design with a track record in numerous applications. The inverter is built with internal power modules. The DC-DC input stage boosts the input voltage to a higher DC voltage, which feeds the DCAC inverter to generate the required AC output. High frequency conversion enables a compact construction, low weight and high efficiency. The input and output are filtered for low noise. High quality built-in fans provide sufficient airflow for operation without derating within the specified temperature range. The fans draw air into the unit, and exhaust at the opposite side of the unit. All heat generating components are installed on aluminum heatsink blocks which are thermally connected to the base plate. This also ensures exceptional mechanical ruggedness. Conformal coating provides protection against humidity and airborne contaminants. Full electronic protection, low component count, large design headroom, and the exclusive use of components with established reliability contribute to a high MTBF. The unit is manufactured at our plant under strict quality control. SPECIFICATIONS Input Voltage 24V, 36V, 48V, 125V, 250Vdc  15% are standard Other inputs available on request Input Protection Inrush current limiting Varistors Internal safety fuse Lower voltage than the specified minimum input will not damage the unit Isolation 1700Vdc input to chassis/output or corresponding to the voltage requirements Output neutral is connected to the chassis internally Floating output as option Standards Designed to meet C22.2 No. 107.1 - 01, UL 458 and EN62368-1 EMI EN 55032 Class A with margins Output Voltage 115Vac /8.7Arms/60Hz or 400Hz; or 230Vac/ 4.3Arms/50Hz 1000VA continuous output voltage Output neutral is connected to the chassis internally Isolated floating output optional Other outputs available on request Output Overvoltage Protection 140Vac (for 115Vac output) or 280Vac (for 230Vac output) by internal supply voltage limiting Output Wave Form Sinusoidal Operating Temperature Range 0o C to +50°C for full specification Extended temperature ranges available Total Harmonic Distortion Less than 5% at full load Line/Load Regulation  6% from no load to full load  2% load regulation option is available Load Crest Factor 2.5 at 90% load Output Noise High frequency ripple is less than 500mVrms (20MHz BW) Output Overload Protection Current limiting with short circuit protection. Thermal shutdown with automatic recovery in case of insufficient cooling Efficiency Input voltage dependent Typically 80% at full load Temperature Drift 0.05% per ° C over operating temperature range Cooling Two high quality built-in fans draw air into the unit Environmental Protection Basic ruggedizing Conformal Coating Humidity 5 - 95% non-condensing MTBF Min. 95,000 hours at 45ºC (Fans excluded) Demonstrated MTBF is significantly higher Fans excluded Indicators Green OUTPUT ON LED installed on internal power card visible through the cooling slots Control Input None Remote shutdown as option Alarm Output None Optional output fail alarm (Form C) Package/Dimensions (H x W x D) 3U2: 132 x 132 x 381 mm 5.2" x 5.2" x 15" excludes connectors, flanges, external fans 3U3: 132 x 187 x 381 mm 5.2 x 7.4 x 15" excludes connectors, flanges, external fans 19” rack-mount version as option Mounting holes are clear Weight 3U2 chassis: 5.2 kg, (11.5 lb.) 3U3 chassis: 6.5 kg (14 lb.) Connections Input: 3-pole terminal block, 13mm spacing Output: 3-pole terminal block.13mm spacing RoHS Compliance Compliant Warranty Two years subject to application within good engineering practice Contamination related failures and shipping cost excluded ABSOPULSE power supplies are designed and built to customer requirements. The specifications on this data sheet are generic guidelines only and are subject to change. OEM of industrial and railway quality DC-DC converters, AC-DC power supplies and battery chargers, DC-AC sine-wave inverters, phase and frequency converters, DC-output UPS systems and complete power systems in 19" and 23" racks since 1982. Custom or standard. ABSOPULSE is a BABT-approved Facility. ABSOPULSE ELECTRONICS LTD 110 Walgreen Road, Ottawa. Ontario. K0A 1L0. CANADA Tel: +1-613-836-3511 | Fax: +1-613-836-7488 https://absopulse.com/contact | https://www.absopulse.com Copyright: This document is the property of ABSOPULSE Electronics Ltd Its content is proprietary and may not be reproduced in html text or any other format. Proprietary notices may not be deleted from data sheets or from other materials downloaded from https://absopulse.com/
