GENESIS Rotary screw compressors
8Pages

GENESIS INNOVATION The new Genesis is a unique all encompassing compressed air station replacing the many individual components that comprise a traditional system, saving you valuable space. The new Genesis includes everything you need to provide a reliable source of high quality, dry, clean compressed air to your system in one convenient unit. LOWER NOISE LEVELS With operating noise levels between 62db(A) and 69 dB(A) the Genesis compressor can be located directly into the working environment and nearer the point of use, creating a more comfortable workplace and reducing installation...

All GENESIS compressors are fitted with a built in air treatment package comprising refrigerant dryer with R134A gas, pre-filter, final-filter and modular condensate drain. The operation of the dryer and condensate drains is conveniently controlled by the compressors main MC2 controller this provides for efficient dew point control of 3°C and allows the fridge compressor to cycle efficiently. The GENESIS is fitted with both pre and final high efficiency filtration resulting in particles, oil and water droplets being removed before entering the compressed air system. The compressed air...

One of the most important factors in achieving increased performance and a longer service life with all rotary screw compressors is the quality of the inlet air. With this in mind, the GENESIS range features a two stage air filtration system; air enters through a cabinet pre-filter panel, which helps to keep the internal components of the compressor clean, as well as maintaining optimum cooling efficiency. The second stage of filtration occurs as the air flows through a highly efficient air suction filter, this ensures that the air entering the compressor element is cleaned efficiently,...

1 3 4 15 2 16 14 5 12 9 10 8 11 7 13 6 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Air end TriAB 51/TriAB 69 Electric motor IP55 MC2 Controller Starter Enclosure Built-in refrigerant dryer, pre-filter and final-filter. Frequency converter fitted to variable speed (I) version Automatic cooling fan Air inlet filter Spin on separator cartridge Spin on oil filter Intake regulator Cabinet pre-filter Air and oil cooler Automatic drive belt tensioner Minimum pressure valve 16 Air receiver Design and technology The GENESIS range is available either mounted on a 270 or 500 liters air receiver, results...

The solid state high quality frequency inverter is housed in the ideal position within the main starter enclosure. The cabinet and cables are fully protected to provide electromagnetic screening to stringent EC directives. A safety cut out switch is located on the door of the enclosure providing additional safety. Approximately 80% of the cost of owning and running an air compressor over 5 years is electricity. Variable speed version Value over a period of 5 years The Genesis I version with advanced high efficiency vectorial frequency inverter offers many advantages over normal air...

ABAC air compressors are manufactured in compliance with: 98/37/CE machinery Directive; 87/404/CE simple pressure vessels Directive; 73/23/CE low voltage Directive; 89/336/CE electromagnetic compatibility; 2000/14/CE noise level. Distributor Abac aria compressa S.p.A. via Einaudi, 6 10070 Robassomero (To) Italy Tel. +39 0119246400 Fax +39 0119241096 e-mail: abac@abac.it www.abac.it CUSTOMER SERVICE A full product support package is available to all of our customers throughout the world. Qualified technical advice and support is provided in strategic locations and in all major countries....
