EMC probe set
5Pages

RF Near Field Probe Set DC to 6GHz EMF & RF close field sniffer-set for use with any Spectrum Analyzer or Measurement Receiver Included with delivery: w w w w w w w w w w 1 x 50mm magnetic field probe 1 x 25mm magnetic field probe 1 x 12mm magnetic field probe 1 x 6mm magnetic field probe 1 x E-field probe Pre-amplifier with power supply (only PBS2) 1m SMB-to-SMA Cable Pistol grip with tripod function Transport case with paddings Exhaustive manual

♦ Pre-Amplifier noise (PBS2): 3.5dB typical ♦ Weight PBS1 (case incl. probes): 1200gr ♦ Weight PBS2 (case incl. probes and pre-amplifier): 1500gr Isotropic E-field probe: ♦ Maximum resonance frequency: >3GHz ♦ Connector: 50 Ohms SMB socket (m) 50mm magnetic field probe: ♦ Maximum resonance frequency: 700MHz ♦ Connector: 50 Ohms SMB socket (m) 6mm magnetic field probe: ♦ Maximum resonance frequency: >6GHz ♦ Connector: 50 Ohms SMB socket (m) 12mm magnetic field sniffer: ♦ Maximum resonance frequency: 2,6GHz ♦ Connector: 50 Ohms SMB socket (m) 25mm magnetic field probe: ♦ Maximum resonance...

Details Our EMC Near Field probe set allows for straightforward pinpointing and measurement of interference sources in electronic component groups as well as execution and monitoring of generic EMC measurement. Our RF near field probe set is especially suitable for: - Pinpointing interference sources Estimation of interference field strength Verification of shielding and filtering measures Identifying faulty components Detecting circuitry overly sensitive to interference Our set includes a total of 5 probes: 4 probes for magnetic field measurement and one for measurement of electric fields....

References User of Aaronia Antennas, Probe Sets and Spectrum Analyzers (Examples) Government, Military, aeronautic, astronautic w w w w w w w w w w w w w w w w w w Airbus, Hamburg, Germany Boeing, USA NATO, Belgium Bund (Bundeswehr), Leer, Germany Bundeswehr (Technische Aufklärung), Hof, Germany Lufthansa, Hamburg, Germany DLR, Germany Eurocontrol (Flugüberwachung), Belgium Australian Government Department of Defence, Australia EADS (European Aeronautic Defence & Space Company) GmbH, Ulm, Germany Institut für Luft- und Raumfahrtmedizin, Köln, Germany Deutscher Wetterdienst, Tauche, Germany...
