Micro-ATX with 12th/13th Generation Intel® Core™ LGA1700 Socket Processors, TDP Max. 125W Industrial Motherboards ■ 12th/13th Generation Intel® Core™ LGA1700 Socket Processors ■ GbE LAN x2 (Optional: Additional 2.5GbE LAN x 2, Intel® I225-LM) ■ Four Independent Displays: HDMI 2.0 x 1, DP x 1, VGA x 1, LVDS/eDP ■ M.2 2242/2280 M-Key x 2, M.2 3042/3052/2242 B-Key + Micro SIM Slot, M.2 2230 E-Key x 1 ■ USB 3.2 Gen 2 x 4, USB 3.2 Gen 1 x 3, USB 2.0 x 2 (Optional: USB Type-C x 1) ■ SATA x 8 ■ Switchable USB Power feature for remote USB device reset ■ Bootable feature in rear USB Port for enhanced security ■ Onboard TPM 2.0 Form Factor Micro-ATX Form Factor, 9.6" x 9.6" (244mm x 244mm) MTBF (Hours) Rear Panel I/O Ports USB 3.2 Gen 2 x 4 (10Gbps) USB Type-C x 1 (Optional, 20Gbps, 5V, 3A) (All ports are bootable, can be deactivated per BIOS function; USB Power switchable feature) DDR5 4000MHz DIMM x 4, Up to 128GB Non-ECC, Un-buffered Memory, Dual-Channel Memory Architecture Audio Jack x 3: Line-in, Mic-in, Line-out RJ-45 GbE LAN x 1 (Intel® PHY I219-LM, supports Intel® AMT 12.0) RJ-45 GbE LAN x 1 (Intel® I210-AT) RJ-45 2.5GbE LAN x 2 (Intel® I225-LM, Optional) Serial Port Realtek ALC897 6-Channel High Definition Audio CODEC Expansion Slots PCIe Gen 5 [x16] x 1 (8 Lanes/8 Lanes when dual-use PCIe [x16] slot) PCIe Gen 3 [x4] x 1 (2 Lanes, Open Slot) PCIe Gen 5 [x16] x 1 (8 Lanes) PCIe Gen 4 [x4] x 1 (4 Lanes) M.2 3042/3052/2242 B-Key x 1 (PCIe 3.0 [x1]/USB 3.2 Gen 1) + Micro SIM Slot x 1 M.2 2230 E-Key x 1 (PCIe 3.0 [x1]/USB 2.0) USB 3.0 x 1 (2x5P 2.54mm Pitch Box Header, supports USB 3.2 Gen 1 x 2) USB 2.0 Header x 1 (2x5P 2.54mm Pitch Box Header, supports USB 2.0 x 2) USB 3.2 Gen 1 x 1 (Type-A, vertical) (All Headers support USB Power switchable feature) 256 Mbit Flash ROM, AMI BIOS — Speaker header x 1 (Line-out), AAFP x 1 Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/3.3V/12V, Fan Monitor on CPU/Chassis Audio I/O Serial Port Parallel Port 12th/13th Generation Intel® Core™ LGA1700 Socket Processors (formerly Alder Lake/Raptor Lake), TDP Max 125W Intel® Q670 Express Chipset WatchDog Timer 1~255 step by software program Power State 4-pin CPU Fan Connector x 1 (PWM Mode) 4-pin Chassis Fan connector x 2 (PWM Mode) 3-pin Chassis Fan connector x 1 (DC Mode) Graphics Chipset Intel® Graphics Media Accelerator Graphics Multi Display HDMI 2.0 x 1, up to 4096 x 2160 @60/30 Hz, with Digital Audio Display Port DP 1.4 x 1, up to 4096 x 2160 @24 Hz or 3840 x 2160 @60 Hz, with Digital Audio Chassis Intrusion x 1 AT/ATX Mode Select Jumper x 1 Front Panel Header x 1 Clear CMOS Jumper x 1 Onboard Buzzer x 1 3-pin ME Lock Header x 1 LED Header for Ethernet x 2 (Optional: LED Header x 4 when RJ-45 x 4) Backlight Control Environment & Power & ME Battery Lithium battery Power Requirement 24-pin ATX connector x 1, 8-pin 12V ATX Power Connector x 1 Operating Temperature Storage Temperature Operating Humidity 0% ~ 90% relative humidity, non-condensing

12th/13th Genera�on (LGA1700 Socket Processor) Industrial Motherboards Block Diagram Port B PCIe Gen3 PCIe Gen3 PCIe Gen3 Thermal Sensor Ordering Information Part Number Expansion Slot SATA III x 8 Intel® LVDS/eDP x 1 M.2 2242/80 M-Key x 2 GbE x 2 USB 3.2 Gen 2 x 4 USB 3.0 Header x 1 USB 2.0 Header x 1 USB 3.2 Gen 1 x 1 (Type-A, Vertical) PCIe [x16] x 2 PCIe [x4] x 2 M.2 3042/3052/2242 B-Key x 1 Micro SIM Card Slot x 1 M.2 2230 E-Key x 1 SATA III x 8 Intel® LVDS/eDP x 1 M.2 2242/80 M-Key x 2 GbE x 4 USB 3.2 Gen 2 x 4 Type C x 1 USB 3.0 Header x 1 USB 2.0 Header x 1 USB 3.2 Gen 1 x 1 (Type-A,...
