BOXER-6617-ADN
1 /2Pages

Catalog excerpts

Fanless Compact Embedded Computer with Intel® Core™ i3 Processor N/Intel Atom® Processor X/Intel® Processor N-series SoC (formerly Alder Lake-N) Compact Fanless BOX PC Solutions Front View ■ Intel® Core™ i3 Processor N/Intel® Atom® Processor X/Intel® Processor N-series SoC (formerly Alder Lake-N) ■ DDR5 4800MHz SODIMM x 1 ■ 2.5GbE x 2 ■ M.2 2280 M-Key/M.2 2230 E-Key ■ M.2 3052 B-Key for 5G ■ SuperSpeed+ USB 3.2 Gen 2 ■ Onboard TPM 2.0 ■ Wide Range 9 ~ 36V DC input ■ Super Wide Operating Temperature -20~70°C Specifications Rear View Intel® Processor N50 Intel® Processor N97 Intel® Core™ i3-N305 Intel Atom® x7211E System Memory Display Interface Storage Device M.2 2280 M-Key x 1 (PCIe [x2]) 2.5" SATA HDD/SSD x 1 HDMI x 2 RJ-45 x 2 for 2.5GbE LAN (Intel® I226) USB 3.2 Gen 2 x 2 (Type-A) USB 2.0 x 4 (Type-A) DB-9 x 6 for RS-232/422/485 Mic-in/Line-out 10-Pin Terminal Block x 1 for Digital I/O 8-channel 3-Pin Terminal Block for DC In x 1 2-Pin Remote On/Off x 1 Reset Button x 1 Power Button with LED x 1 M.2 2280 M-Key x 1 (PCIe [x2]) M.2 2230 E-Key x 1 (for Wi-Fi) M.2 3052 B-Key x 1 (for 5G/LTE) SIM Slot x 1 Windows® 10 IoT Enterprise Linux Ubuntu 22.04 Power Supply Power Requirement DC-in 9-36V x 1 for 3-Pin Terminal Block Mechanical Mounting Wall Mount Gross Weight Environmental Operating Temperature Storage Temperature 3 Grms/ 5 ~ 500Hz/ operation (with SSD) 50G, IEC 68-2-27, half sine, 11 ms duration (with SSD) Storage Humidity -4°F ~ 158°F (-20°C ~ 70°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM)

Open the catalog to page 1

Compact Fanless BOX PC Solutions Ordering Information Part Number Operation Temp. -4°F ~ 158°F (-20°C ~ 70°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM) M.2 2280 M Key Slot x1 (PCIe x2) 2.5" SATA Drive Bay x 1 M.2 2280 M Key Slot x1 (PCIe x2) 2.5" SATA Drive Bay x1 -4°F ~ 158°F (-20°C ~ 70°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM) M.2 2280 M Key Slot x1 (PCIe x2) 2.5" SATA Drive Bay x1 -4°F ~ 158°F (-20°C ~ 70°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM) M.2 2280 M Key Slot x1 (PCIe x2)...

Open the catalog to page 2
