Products E9 New! Temperature Products MADE IN USA Model POC 1” Testing and Spot Checking Thermometers DESCRIPTION SPECIFICATIONS U.S. Gauge offers a pocket sized thermometer used by inspectors, service and maintenance personnel, and technicians for general checking in food service, refrigeration, air conditioning, hot asphalt, and food processing applications. These thermometers have a .15” standard stem diameter and a threaded connection that can be adapted for OEM applications with limited space considerations. STEM LENGTH: 5” (127 mm) STEM DIAMETER: .15” CONNECTION: Recal nut is standard EXTERNAL RESET: Friction nut design for easy calibration CONSTRUCTION: 304 stainless steel external parts, welded construction; corrosion resistant to most chemicals HERMETIC SEAL: Per ASME B40.3, dustproof and leakproof DIAL: Anodized aluminum with large black numbers and graduations LENS: Polycarbonate lens is standard BIMETALLIC COIL: Helix coil is silicone coated on ranges below 500ºF for vibration dampening and to maximize heat transfer and response time ACCURACY: ±1% full span per ASME B40.3 Grade A OVER TEMPERATURE LIMITS: Up to 250ºF, 100%; 250º to 550ºF, 50%; 550º to 1000ºF, continuous use up to 800ºF, intermittent use over 800ºF POCKET SHEATH: Standard STANDARD RANGES: FAHRENHEIT DEGREE DIVISION *0º to 250º 2º increments *50º to 500º 5º increments * Additional ranges are available – please consult factory at (863) 534-1504 NSF® approved for food service applications .40 (10.16) .102 (2.59) SPEC NUMBER SELECTION CHART INCHES (MM) ø.15 (3.81) Model POC-1 1.004 (25.5) 1" Dial Size 5" Stem Length Connection 1/2-14 NPT 50 to 500ºF 415000 0 to 250ºF STEM LENGTH Temperature Range 415001 Spec No. © 2006, by AMETEK, Inc. All rights reserved. PDF606 (160126) Specifications are subject to change without notice. Visit our Web sites for the most up-to-date information. For Gauges/Thermometers: For Electronic Products: U.S. GAUGE PMT PRODUCTS For Diaphragm Seals: M&G PRODUCTS 820 Pennsylvania Blvd. Feasterville, PA 19053 U.S.A. Tel: (215) 355-6900 Fax: (215) 354-1802 www.ametekusg.com Customer Service Tel: (863) 534-1504 Customer Service Fax: (863) 533-7465 820 Pennsylvania Blvd. Feasterville, PA 19053 U.S.A. Tel: (215) 355-6900 Fax: (215) 354-1800 www.ametekusg.com 8600 Somerset Drive Largo, FL 33773 U.S.A. Tel: (727) 536-7831 Fax: (727) 539-6882 www.ametek.com/tci
