Rion angle level switch LCA331&LCA332

Rion angle level switch LCA331&LCA332
1 / 10ページ

カタログの抜粋

Rion angle level switch LCA331&LCA332 - 1

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH Appearance Patent No: 201830752874.1 RoSH certification: 18300RC20410801 V1.4 SWITCH OUTPUT TYPE TILT SWITCH

カタログの1ページ目を開く

Rion angle level switch LCA331&LCA332 - 2

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH ○ RoHS certification:18300RC20410801 ○ China National Intellectual Property Appearance Patent (Patent No : 201830752874.1) ○ Revision time:2024-08-07 Note: Product functions, parameters, appearance, etc. will be adjusted as the technology upgrades. Please contact our pre-sales business to confirm when purchasing. Disclaimer This product is developed exclusively for commercial applications and is prohibited from being used for illegal purposes, such as military activities, research related to nuclear, chemical, or biological weapons, or any other...

カタログの2ページ目を開く

Rion angle level switch LCA331&LCA332 - 3

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH ▶ GENERAL DESCRIPTION LCA331A series a low cost tilt switch developed by RION for application like level safety alarming and platform level monitor and alarm. Alarm threshold value is pre-setable. when the inclination exceed set alarm value, it will output switch output signal(output voltage=input voltage), to drive the solenoid valve hydraulic system or drive buzzer or alerming light for the safety of platform. Its main function is to monitor and alarm the(dual axis or single axis) inclination of platform automatically. LCA331A series tilt switch...

カタログの3ページ目を開く

Rion angle level switch LCA331&LCA332 - 4

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH Measure range Measure axis Measure accuracy Long-term stability Zero temp. coeffiecient Temp.Sensitivity coefficient Response time Electromagnetic compatibility MTBF Insulation Resistance Impact resistance 100g@11ms、3 axial direction (half sinusoid) Protection grade Direct lead IP67; Aviation plug IP65 1m, durable, grease proof, wide temperature, shield cable, 4*0.4 mm2 140g(without cable) Cables Weight ▶ ELECTRONIC CHARACTERISTICS PARAMETERS Power supply Alarm output current Working current Working temperature Store temperature KEY WORDS...

カタログの4ページ目を開く

Rion angle level switch LCA331&LCA332 - 5

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH ▶ MECHANICAL PARAMETERS ○ Connectors : 1m lead cable (Length can be customized) ○ Protection glass : IP67 ○ Enclosure material : Aluminum Oxide ○ Installation : 4*M6 screws E.g: LCA331A-P005 : single axis/1 way output/positive output/0.5deg alarm note: 1) Please place order according to the order description; 2) The factory default alarm threshold value is +-2deg, if other value required, please order refer to the order information; 3) The positive ,negative direction explanation : (positive direction) usually does not alarm, exceed the alarm...

カタログの5ページ目を開く

Rion angle level switch LCA331&LCA332 - 6

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH the alarm threshold. 2) there is no preset angle value function for dual axes double wires 3) connection of RXD and TXD function, see below drawing. 4) If you are using a laptop debugging you also need a RS232 to USB module, if the PC can be directly connected communication with the computer COM port.( If use converter must install conversion module driver can be use) Above figure is the working principle diagram of the dual-axis , the output is high-low level signal, in this figure, when the tilt reaches the preset value of the positive X...

カタログの6ページ目を開く

Rion angle level switch LCA331&LCA332 - 7

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH SIZE : L60XW60XH29MM Installation size: L48 x W48 x H4mm Mounting screws: 4 M4 screws ▶ MEASURE DIRECTIONS&FIX The installation must guarantee the product bottom is parallel to measured face，and reduce the influence of dynamic and acceleration to the sensor. This product can be installed horizontally or mounted vertically (mounted vertically selection is only applicable to the single axis, and only can do relative measurement , if absolute measurement the level reference will occur error ), for installation please refer to the following scheme.

カタログの7ページ目を開く

Rion angle level switch LCA331&LCA332 - 8

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH ▶ PRODUCTION INSTALLATION NOTES Please follow the correct way to install tilt sensor, incorrect installation can cause measurement errors, with particular attention to mounting surface and the measured surface must be fixed closely, smoothly, stability,if mounting surface uneven likely to cause the sensor to measure the angle error. The sensor axis and the measured axis must be parallel ,the two axes do not produce the angle as much as possible. ▶ RION PRODUCT DEBUGGING SOFTWARE If you want to change the alarm thresholds, can communicate with...

カタログの8ページ目を開く

Rion angle level switch LCA331&LCA332 - 9

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH Debug process: 1) Open software; 2) Select the corresponding COM port, refer to 2”. 3) Other settings are default setting , no need to set. " 4) Click to open the serial port button, refer to 2 " 5) This data will display in the return data area, refer to 3” 6) If you want to set the alarm threshold, please input setting alarm threshold command in input area, refer to 4" . ( For command please refer to the specification of communication protocol .) 7) When the return data area display " command +Okay" proved successful setting. Refer to 5” Common...

カタログの9ページ目を開く

Rion angle level switch LCA331&LCA332 - 10

LCA331&332 SWITCH OUTPUT TYPE TILT SWITCH Byte2：＋/- The tens column of axis angle value The single digit of axis angle value The decile of axis angle value The percentiles of axis angle value Format as following： ITEA SIGNE DAT M D A SPAC SPAC ITEA SIGNE DAT ENTE NEWLIN E E M D A R E Blank Blank X +/**.** Y +/**.** Enter Line feed space space E.g：the current X axis angle is +01.50deg，Y axis - 01.00 deg, then display X＋01.50； Y－ 01.00 Note: If the user set the relative zero when power on last time, then power on this time, the system will output：“relative angle measure!” 2. The relative...
