CORE ANALYSIS EQUIPMENT Core Flood System ADVANCED ROCK PROPERTIES Core Flood System Email: service@rigchina.com Website: http://www.rigchina.com SKYPE:RIGCHINA

CORE ANALYSIS EQUIPMENT Core Flood System gigCHINA RESERVOIR CONDITIONS COREFLOODING SYSTEM - is a automated, modular Core Flooding system that is configured for unsteady-state relative permeability tests. Core Flooding experiments in single and multi phase displacements are available in manual and automatic mode, addition of the gas delivery system allow performance of gas displacement experiments. In addition to relative permeability experiments the system is capable of performing a range of reservoir quality assessment experiments including: critical velocity, brine sensitivity, return...

CORE ANALYSIS EQUIPMENT Core Flood System gigcHiNA Highly corrosion-resistant construction throughout Inert construction throughout Unique split oven design for easy access to all components Unique Test Sequencer software module allows the user to predefine test sequences that can be saved for future use SPECIFICATIONS: Maximum confining pressure: 10,000 psi (70MPa)- Higher pressures available Maximum pore pressure: 6,000 psi (50MPa)- higher pressures available with different pumps Maximum operating temperature: 360 °F (180 °C) - Higher temperatures available Routine Core length: 25mm (1")...

CORE_ANALYSIS_EQUIPMENT Core Flood System Working Schematic: 1 Thermostatic System • Hand Pump Assembly Pressure Sensor Routine Coreholder Special COreholder

CORE ANALYSIS EQUIPMENT Core Flood System Figure of Core Flood System: Gas Tank Confining Pressure Pump OVEN Computer Console Windows Email: service@rigchina.com Website: http://www.rigchina.com SKYPE:RIGCHINA

CORE ANALYSIS EQUIPMENT Core Flood System

CORE ANALYSIS EQUIPMENT Core Flood System Email: service@rigchina.com Website: http://www.rigchina.com SKYPE:RIGCHINA

CORE ANALYSIS EQUIPMENT Core Flood System

CORE ANALYSIS EQUIPMENT Core Flood System gigcHiNA Scope Of Supply Oven Windowed Environmentally Safe Oven (Air Bath) rated to 450°F (±1 degree) minimum with automatic temperature control, lighted interior and emergency venting safety features. Allows pumps to be mounted inside the oven to eliminate thermal gradients in the re-circulating fluids. Figure of Oven Email: service@rigchina.com Website: http://www.rigchina.com SKYPE:RIGCHINA

CORE ANALYSIS EQUIPMENT Core Flood System Piston Syringe Pump The dual piston syringe pump module includes controller and manifold. The pump features continuous pulse-free fluid delivery at either constant flow rate or constant pressure and at pressures up to 7,500 psi. Capacity 200 ml; minimum flow rate 0.001 milliliters per minute;maximum flow rate 80 milliliters per minute.

CORE ANALYSIS EQUIPMENT Core Flood System gigCHINA Accumulator Stainless Steel construction floating piston design complete with valves, rack mounted. Capacity: 1,000 cc. Working Pressure: 10,000 psig, Wetted material: 316 Stainless Steel Temperature rating up to 350 deg F. (180 °C) Email: service@rigchina.com Website: http://www.rigchina.com SKYPE:RIGCHINA

CORE ANALYSIS EQUIPMENT Core Flood System Tri Lock Core Holder Hydrostatic (Biaxial) with 316 Stainless Steel wetted parts configured with static ports for accurate pressure differential measurements with 3 inlets and 2 outlet flow ports Wetted material: 316 Stainless Steel, Seals/Sleeves: Viton. Core Diameter: 25mm (1.0)" and 38mm (1.5"); Core Length: 25mm (1") to 150mm (6") standard (other lengths available upon request) Working Pressure: 10,000 psi; Working Temperature: 360 °F (180 °C) Routine Coreholder Mold 25 X (25 120) I y ij i i i \ j i £ i ?fJ. _

CORE ANALYSIS EQUIPMENT Core Flood System Differential Pressure System Differential Pressure System, consists of two high accuracy transducers accurate to 0.1% full scale and a separate array of four differential pressure transducers, accurate to 0.5% full scale, is provided to maintain accuracy at low differential pressures. 0 to 8, 0 to 80, 0 to 200 and 0 to 500 psid. All transducers are interfaced to host computer and data collected and stored by the operating program. Line pressure: 10,000 psi Automated Overburden System Automated Overburden System, controls the effective net overburden...

CORE ANALYSIS EQUIPMENT Core Flood System Data Acquisition and Control Data Acquisition and Control: PC based control software that includes a PC system with a 19-inch LCD Screens, 1 TB minimum Hard Drive CD-DVD and high-speed USB interface for system operation. System software displays and logs all input/output data in real time, monitors all flow and pressure conditions and allows for both manual and automatic operation of system components normally operated in this type of equipment. Real time graphs and animation allow operator to easily visualize condition of the experiment. Includes...

CORE ANALYSIS EQUIPMENT Core Flood System Data Acquisition Process-Tessure Sensor r-'-rii-rj PYrtBlHfl PUtiD emperature Sensor SE5 FlOW Mete" D-ata fuiqwHtlrjn System u;mp'j:er Electrical Balance -onstan' Dra5jj-e Lc-nstant speed pjtip Auto Control Asitnbly Ovcr-ri'-Mir'1 Kml'f-rli-nn Synrr’Ti

CORE ANALYSIS EQUIPMENT Core Flood System Data Acquisition Software All instruments and instrumentation sub-systems were manufactured or assembled in the China（Rigchina Group）Specifications subject to change without notice 1
