PMIB3

PMIB3
1 / 7ページ

カタログの抜粋

posimag® lin Magnetic Scale Position Sensors PMIB3 Magnetic measuring scale for posimag® sensors Adhesive magnetic tape, applicable also on curved surface With stainless steel base

カタログの1ページ目を開く

PMIB3 - Magnetic measuring scale for adhesive taping Specifications ‒ Magnetic measuring scale PMIB3 Order options Magnetic period Solid measure Plastic bonded flexible permanent magnet (elastomer) Base material Stainless steel CrNi 17 7 Mounting / scope of supply Version N: adhesive taping, with reference marks, with adhesive tape Measurement range e.g. 100, 500, 1000 ... 30000 mm, up to 50 m on request; further measurement ranges must be divisible by 4 (magnetic period 2 mm) or by 10 (magnetic period 5 mm) resp. Reference marks / end position marks (optional) R1= reference mark on the...

カタログの2ページ目を開く

PMIB3 - Magnetic measuring scale for mounting on profile Specifications ‒ Magnetic measuring scale PMIB3 in flat profile or high profile Order options Magnetic period Solid measure Plastic bonded flexible permanent magnet (elastomer) Base material Stainless steel CrNi 17 7 Mounting / scope of supply Version M: mounted on flat profile or high profile, available up to 2800 mm max. Version S: scope of supply as for version M, but not mounted Measurement range Further measurement ranges must be divisible by 4 (magnetic period 2 mm) or by 10 (magnetic period 5 mm) resp. Linearity at 25°C...

カタログの3ページ目を開く

Position of the reference marks Reference mark dimensions Magnetic period Magnetic period 2 mm with high profile 5 mm with high profile 2 mm 5 mm 2 mm with high profile 5 mm with high profile Position of the end position marks End position mark dimensions

カタログの4ページ目を開く

Accessories Masking tape PMAB Masking tape made of stainless steel for posimag® magnetic scale PMIB3, width 10 mm, thickness 0.2 mm Order code Flat profile PMFP Mounting element PMFP-BFS1 High profile PMHP Mounting element PMHP-BFS1 Dimensions in mm [inch]. Dimensions informative only. For guaranteed dimensions consult factory.

カタログの5ページ目を開く

Slider for high profile PMGW3 Dimensions in mm [inch]. Dimensions informative only. For guaranteed dimensions consult factory.

カタログの6ページ目を開く

Chemical durability – Elastomer magnetic scales (PMIB3) no / little influence weak / middle influence strong influence motor oils gear oils ATF (automatic transmission fluid) hydraulic fluid kerosene antifreeze agent purifying agent turpentine water sea water/salt water JP-4 fuel (Jet fuel) gasoline/petrol heptane alcohol aromatic hydrocarbon (benzene, toluene, xylene) ketone anorganic acids (HCl, H2SO4)
