testXpert •The BasicLine is especially suited for routine andfunctional testing of components and for simple
materials testing.•With the Zwick Roell develops and produces testing machines forforces from the mN range up to more than 6000 kN.
As opposed to the often offered single-purpose testing
instruments, Zwick Roell offers testing machines with
individual solutions for each testing requirement. A
customer specific testing machine is put together for
each testing application.Following is an overview of the different variations of loadframes, the multitude of testing tools and devices, the
advantages of the testing software Standard series the user who wants testsreliably performed to test requirements of Standards,
receives a solid solution which is cost favourable.•The Allround series is the expandable machinefor demanding test requirements in research and
development. It enables the connection of special
sensors, allows multi-channel measurement
technology and can be expanded modularly.In each of these series we offer:• 1-column table-top machines („zwickis“)• 2-column table-top machines • Floor machines (not in the BasicLine)
® , as wellas several of the options available.We would also be happy to specify the correct testingmachine for you and your application.
3.1 Load frame
The Zwick Roell program has table-top and floor
machines with various measurement, control and
regulating systems, different drives and many multi-use
accessories.In order to be able to offer the correct machine with theoptimum price-performance ratio, the Zwick Roell
machine concept has three machine series which are
very different in their equipment, performance
characteristics and in their expansion possibilities: Basic concept
Picture 43a/b: Testing machines of the Allround series:
A 1-column table-top machine (left) and a floor machine (right)
Picture 42a/b: Testing machine of the BasicLine:A 1-column (left) and 2-column (right) table-top machine
Picture 41a/b: Testing machines of the Standard series:A 1-column (left) and 2-column (right) table-top machine 23
