testXpert Expanded traceability forelectronic records, e.g. for FDA
21 CFR Part 11 This option can be applied for allsafety critical tests that impose
expanded requirements on the
traceability and documentation of
data gathered during testing. This
option is also ideal for creating the
necessary prerequisites for fulfilling
the requirements as in FDA 21
CFR Part 11. These guidelines as
published by the US foodstuffs
and health department FDA
(Food and Drug Administration)
contain technical and organisatory
requirements on electronic
recording of data.The
Video-Capturing during
the functional
test of a rubber joint Data saving for further use Video Capturing
Depending upon the preselection inthe test program, not only all data
but also selected result data from a
test or test series can be saved.
Saving of all data offers the possi-
bility of tracing the origin of the
result data up to configuration and
settings for the test machine. The
standardized measurement data,
i.e. the data converted to its basic
units can be repeatedly displayed in
the simulation mode and can also
be evaluated according to other
criteria. testXpert
® not only supports the userby means of “Help” videos. It is also
possible to carry out multimedia
tests by using a video
professional camera and
a video-capture card with the video
pictures being recorded time-
synchronously with the test data.•With the cursor keys, a “videoreticle” can be moved over the test
curve and the corresponding
picture can be displayed•The pictures can be captured at apreselected distance of the
measuring points or in depen-
dence on the event•The video can also be playedalone, irrespective of
testing machine manufacturers•Distances between two points andangles between three points, radii,
diameters and areas can be
measured from the specimen in
pictorial representation•Optionally, the pictures can also beoutput with dimension lines and
test data
® option offers toolsthat, together with organisatory
procedural sequences in the
companies in question, fulfill the
regulations of 21 CFR Part 11.
26
