Windows-Software is normally usedin offices. However, testXpert Security in detail

Zwick/Roell test software

In addition, testXpert
® checks if•the test can be performed withthe specified configuration,•all settings have been made and •the data has been changed for thenew testing.

testXpert

® repeatedly displayed in thesimulation mode as well as evaluatedaccording to other criteria. The complete development processof the software and its components is carefully documented and archived for every version and for every phase from analysis to specification, design, implementation, and up to test. This is done from the source code up to the software tools used. Conformity with Standard ISO 9000-3 has been confirmed with audit report No. QM-F-96/1016. Video capturing Simple operation testXpert The test software testXpert
® notonly supports the user by means of „help“ videos. It is also possible to carry out multimedia tests by using a video camera and a video capture card, with the pictures being recorded time-synchronously with test data (Fig.13). Operation is reduced to a one-button, i.e. activating the start button, for standard applications. This is possible because Preparation of a test series requiresonly 2 steps:•Loading the desired test program.•Input of the variable parameters
® automatically records the test data,controls and monitors the test sequence, and determines and stores the test results. Only two steps to testing •With the cursor keys, a ”videowindow” can be moved over thetest curve displaying the corresponding picture.•The pictures can be capturedat pre-selected measuring points or at a specified event.•The video can also be playedalone apart from the industrial testing machine.•The picture can be used tomeasure distances between two points, angles between three points, radii, diameters, and areas.•Alternatively, the pictures canbeexported with dimension lines and test data.
® takes over an additional, especiallycritical task: monitoring and controlling machines. testXpert TestXpert Automatic acceptanceof system data
® does not use overlapping windowsin the test mode in order to avoid hiding important displays or key fields. This will prevent injury to personnel and damage to the machine. Various test jobs require separatetesting machines with different interchangeable components. The specific jobs are characterized by the system data (nominal force, travel, speed range, mounting height, calibration factors etc.). System data also belongs to the above, e.g. the series number or date of the last calibration. Optimum user information All displays necessary for carryingout a test and a test series can be grouped together in a clear and concise manner in one single screen setting: •Input fields for specimen-specific testing parameters•Curve diagrams (individualor multiple curves)•Table for test results •Table for test result statistics Depending upon specific selectionsin the test program, selected results and test parameters of a single test or test series can be saved along with the data curve. Saving of all data offers the possibility of tracing the result data from the original data to the configuration and settings for the testing machine. The standard- ized measurement data, i.e. the dataconverted to its basic units, can be Data saving for further use
® reads in this dataautomatically after starting the program: •for the specific test settings, •for determination of safety limitvalues,•for the correct measurementsignal evaluation.
Fig. 13: Box compression test using video- capturing 11
