Zw/ck / Roell
test-curve in testXpert®
Application
Example of mounting
Tensile test
Standard: EN 10001-1, ISO 10275
ISO 10113 Type of test: Tensile test with determ.
of r- and n-value Material: steel sheet Extensometer: Macro with reduction
in width monitor Grips: Wedge-screw
testXpert®: B069008
Standard: Type of test: Material: Grips: testXpert®:
EN 10138 Tensile test Strand Hydraulic B069008
Standard: DIN 488, EN 10080 Type of test: Tensile test Material: Steel wire for the
reinforcem. of concrete Extensometer: Macro Grips: Hydraulic
testXpert®: B069008
Standard: EN 10002-5
Type of test: tensile test Material: steel Extensometer: HT-Extensometer Grips: Thread
testXpert®: BX069008.00xx-08
8
