ZMART –
Zwick Modernizationand Retrofit Technology
Modernization packages testXpert
® are available.The decision regarding thepurchase of a new machine
and a modernization primarily
depends on the value and technical
condition of the machine
components to be taken over.
Due to the fact that in addition to
the load frame other components
can be used furthermore, as e.g.:
load cell and extensometer, the
costs for a modernization remainrelatively low compared to the
costs incurring for the purchase
of a new machine.The modernization packagesare composed of the following
components:
•Digital measurement and controlelectronics•Test software With the modernization packages ZMART.KIT
® and ZMART.PRO
® both electro-mechanical andhydraulic materials testing machines of different manufacturers
can be upgraded and brought to
the most recent state-of-the-art.
After a modernization the
guaranteed spare parts supply for
modernized components, the entire
accessory program includingextensometers or specimen grips
and in particular also the most
recent version of the test software testXpert
® •Maintenance-free AC-drives
•Proportional valves or servovalves and hydraulic units for
hydraulic testing machines
Special features or services ZMART.PRO
® testControl Allround (DUPS) M
1) H
2) M
1) H
2) I
3) Connection to
•
Electro-mechanical testing machines - --
•
Quasi-static hydraulic testing machines- -
•
Can also be used without Personal Computer (PC) ---
•
Can be used with up to 3 hydraulic testing machines--- - Test
data acquisition and display •Test force and crosshead or piston travel resp. Connection of:
•
Analog
extensometers (inductive)
•
Analog extensometers (
strain gauge system)
•
Incremental extensometers
•
Several
industrial load cells (changeover via testXpert
® ) Test data storage and processing
•
Display of maximum force and travel when reaching --- the test end criterion (without PC)
•
Optional display of test force or stress, travel and/or deformation or strain (only with PC)
•
Output of XY-curves with the coordinates force/stress, travel and/or deformation/strain or test time (only with PC)
•
Automatic determination and documentation of materials characteristic data and statistical data (only with PC) Test sequence and test speed control
•
Automatic recognition of the test end (specimen break, force- - travel or time limit value or number of test cycles reached)
•
Automatic stop at test end or return to start position -
•
Automatic speed changes according to the - test program (only with PC)
•
Test speed control in dependence on the measured - force or deformation („closed-loop“-control), only with PC and optional program) Monitoring of safety limit values
•
Test force -
•
Crosshead- resp. piston travel -
1) For electro-mechanical testing machines 2) For hydraulic testing machines, 3) Only data aquisition and display 34
