Zw/ck / Roell

Pendulum impact tester Application

With pendulum impact testers Charpy and IZOD impact tests as well as tensile impact tests are carried out.

Features

• Rigid, distortion-free frame with low-friction pendulum bearing.

• Electromagnetic safety brake and auto-lifting device for the pendulum (from 50 J on)

• Analog dial display for the

reading of the absorbed impact energy and angle and intelligent digital display for the direct reading of the absorbed impact energy

• User-friendly test software testXpertt® - as option

• Accessories easy to change

Technical data

See table pendulum impact testers

Ductility testing machines manufacturer

Application

• Testing of the formability of sheet metal

• Testing of the influences of surface treatments, coatings and lubricants for typical types of deformation (deep drawing, stretching and forming)

• Test tools for Erichsen- and Olsen cupping tests, cupping draw test, Fukui test, Bulge test etc

Special features

• Simple and fast exchangeability of the test tools as e.g. shaping ram, deep drawing die, sheet metal holder, blanking punch, die ring and sheet metal scraper.

Ductility testing machine Amsler BUP 200

• Test tools from previous models

to be used without restriction or modification.

• Quiet, clean operation and easy to transport for the use in laboratories, offices or seminar rooms.

• Low piston-to-cylinder friction for precise measurements and reproducible test data records.

Technical data

See table ductility testing machines (BUP)

Pendulum impact tester Zwick 5113


Ductility testing machines
Series/type	Amsler	Amsler	Amsler	Amsler
	BUP 100	BUP 200	BUP 400	BUP 600
• Max. cupping force, kN	100	200	400	600
• Max. sheet met. clamp. force, kN 25		25	30	50
• Punching force, kN	-	150	250	600
• Max. test stroke, mm	80	80	120	120
• Max. test speed, mm/min	235	750	750	750
• Circular blank diameter, mm	80	170	210	260
• Max. sheet met. strip width, mm	120	120	160	260
• Max. sheet met. strip thickn., mm 2		4.5	4.5	10
• Circ. blank punch diameter, mm	-	120	160	220
• Test punch diameter, mm	60	75	90-105	100
• Max. power consumption, kVA	7.5	7.5	15	20

Pendulum impact tester Amsler RKP 450
