1) See table high-frequency testingmachines (HFP)
Series/type
2) HCHBHA •Construction typetable topfloor stand.floor stand.
Measurement and controlsystem
•Load frame nominal force, kN5 - 2550 - 1,00050 - 500 •Test stroke, mm100100/250/400100/250 •Specimen length, mm100 - 700100 - 1,100250 - 1,500
Measurement and control of thesetesting machines is taken over by
the measurement and control
electronics VibroWin
•Hydraulic unit * System pressure, bar210/280210/280210/280 * Flow, l/min 4 – 239 – 6009 - 600
® .The data selected by the operatoras well as the set values and actual
values are digitally displayed on the
screen.
•Max. power consum., kVA2.2 – 112.2 – 742.2 - 74
1) Load frames and actuators for higher nominal forces on request 2) In the HC and HB serie the actuators are situated in the upper crosshead, in the HA serie
in the lower crosshead High-Frequency testing machines (HFP)
Series/typeAmsler HFP 1 - 5Amsler HFP 20 - 550
Rotary bending testingmachines
•Construction typetable topfloor standing •Load frame nominal force, kN1 - 520 - 550 •Max. force amplitude, kN2.5275
Application
•Max. elast. spec. deform., mm± 3± 2
See table rotary bending testingmachines (UBM)
•Frequency range, Hz35 - 30035 - 300
With the rotary bending test, thefatigue strength of round
specimens under reversed bending
stresses is determined.
•Frequency levels516/5
Technical data
•Working area width, mm350530/600 •Max. power consum., kVA25
Rotary bending testing machines (UBM)
Series/typeAmslerUBM 200Amsler UBM 2000 •Max. bending moment, Nm2002,000 •Load reversal frequency, min-150 - 5000600 – 3000 •Max. specimen diameter, mm2550 •Max. power consum., kVA1.6 5.5
Rotary bending testing machine
Amsler UBM 200 28
