Series/typeTC-EXMACROTC-EXLONGS • DescriptionMacroLong stroke •Gauge le ngth, mm10 bis 100/20510 bis 1,000 •Gauge length adjustmentmanual or automaticmanual •Method of attachmentmanual or automaticautomatic •Measurem. travel, mm80/120/160/75/112,5/1501,000 – L
•Resolution, µm0.12/0.18/0.24/0.3/0.45/0.65
Incremental reduction in width monitor
Series/typeTC-EXMACWDTC-EXMACWD •Application withMacro and long strokeMacro and long stroke •Specimen width, mm10 to 15/20 to 25 (2 steps)10 to 25 (1 step)
Macro extensometer with reduction inwidth monitor
Incremental clip-on extensometer •No. of measurem. levels2/41/4 •Gauge length adjustmentmanualmanual •Method of attachmentmanual or automaticmanual or automatic •Measurem. travel, mm5>6 •Resolution, µm0.02/0.10.02/0.1
Incremental clip-on extensometer (for manual operation)
Series/typeTC-EXICLEL.001TC-EXICLEL.002 •DescriptionIncrementalIncremental clip-on extensometerclip-on extensometer •Gauge length, mm20/25/3050/55/65/70 (optional 50/80)(optional 80/85/100/105) •Spec. thickn./diam., mm20x30 or Ř 2020x30 or Ř 20 •Measurem. travel, mm+13.5/-0.2+40/-0.2 •Resolution, µm0.10.1 Series/typeTC-EXICLWDTC-EXICLBITC-EXACLWD .001.001.001 •DescriptionIncrementalBiaxialStrain gauge reduction inincrementalreduction in width monitorclip-on extens.width monitor •Spec. thickness, mm10 to 2010 to 2010/12.5/20/25 •No. of measurem. levels112 •Measurem. travel, mm1.5 to 11.51.5 to 11.54 •Resolution, µm0.10.10.04
Contactfree extensometers
Series/typeTC-EXOPTICTC-EXLASERTC-EXVIDEO • DescriptionOptical LaserVideo extensometer.extensometer.extensometer • Gauge length (L
), mm10 to 90010 to 5005 to 1,000 • Measurem. travel, mm900 minus L
max. 1,000 % to L
= 20 mm50/100/200/500/1,000, dep. on resolution • Resolution, µm5120.5/1/2/5/10 • Travel transducerincrementallaser scannervideo, analog
23
