| | | Servohydraulic Testing Machines Application These machines are used primarily for dynamic tensile, compression, and bending tests. The tests may include standard LCF, HCF or fracture mechanics testing. Special Features • Extremely-stiff load frame with a manually or hydraulically adjustable crosshead | | |
| | | • Highly-resilient actuator with high-precision guidance, ensuring maximum stiffness in all testing planes • LVDT transducer (installed centered in the piston rod) with high resolution, linearity, and durability. • High-performance hydraulic power supply • Low noise level due to an internal gear pump • Water or air cooling option for the hydraulic power supply | | Measurement and Control Electronics Unrivalled performance is offered using the HydroWin 96xx controller series Features include: • 19-bit A/D conversion with realtime linearization • MIMICS advanced adaptive control for automotive test applications • Environmental management • Multi-channel control The digital measurement and control electronics Zwick HydroWin® 9600 features connections for external sensors as well as extensive application software. | | |
