Multi-axial Test on Air Bearings Zwick’s customer needed to deter-mine the performance and quality attributes of an air spring under axial and horizontal loading conditions. This system consists of a Zwick floor-standing 250 kN test machine adapted with a horizontal electro- mechanical drive and a load mea- surement platform with five force transducers to measure the complex loads. Finally, the system is equipped with a horizontal loading carriage which facilitates loading of the test specimen and horizontal articulation. Axial Fatigue of ProductionDampeners A Zwick tabletop servohydraulic testsystem is used to perform dynamic tests on elastomeric and metal dam- pener component in a production environment. Typical properties determined may include spring constant, dynamic modulus, phase shift and dynamic performance over a specified frequency range (E.g. sine sweep). The system consists of safety “light curtain” and requires operator to place both hands on starter panel prior to machine operation.
Air bearing specimen and fixturingAir bearing test rig axial and horizontal loading Production system for fatigue testing of elastomer industrial dampers 12
