External Dimensions Units: mm

• Flange Output Face

CO I—

o o E o >

0) <*) >-co o cc



	02ADAH101 (02ADAH10C)	1/5	165 (205)	21	30	.i .,+0.018 '⁴ 0	40	6-M4 x 7L	1.8 (2.4)
	02ADAHB01 (02ADAHB0C)	1/11	165 (205)	21	30	.i .,+0.018 '⁴ 0	40	6-M4 x 7L	1.9 (2.5)
	02ADAHC01 (02ADAHC0C)	1/21	178 (218)	27	45	+0.021 ²⁴ 0	59	6-M6 x 10L	3.4 (4.0)
	02ADAH701 (02ADAH70C)	1/33	178 (218)	27	45	+0.021 ²⁴ 0	59	6-M6 x 10L	3.4 (4.0)
	04ADAH101 (04ADAH10C)	1/5	183.5 (223.5)	21	30	_H .,+0.018 14 0	40	6-M4 x 7L	2.2 (2.8)
	04ADAHB01 (04ADAHB0C)	1/11	196.5 (236.5)	27	45	+0.021 ²⁴ 0	59	6-M6 x 10L	3.8 (4.4)
	04ADAHC01 (04ADAHC0C)	1/21	196.5 (236.5)	27	45	+0.021 ²⁴ 0	59	6-M6 x 10L	3.8 (4.4)
	04ADAH701 (04ADAH70C)	1/33	237.5 (277.5)	35	60	32+0.025	84	6-M8 x 12L	7.4 (8.0)

Notes: 1 The models and values in parentheses are for servomotors with holding brakes.

2 Dimensions not found in the table above are the same as those in the table on the previous page.
